10.23 COMMAND #170: SET CURRENT RANGE
This command sets the 4-20mA analog output range.
Request Data Bytes
Byte
0
Unsigned-8
Response Data Bytes
Byte
0
Unsigned-8
Command-Specific Response Codes
Code
0
1 - 2
3
4
5
6 - 127
10.24 COMMAND #171: SET DETECTION MODE
This command sets the Detection Mode.
Request Data Bytes
Byte
0
Unsigned-8
Response Data Bytes
Byte
0
Unsigned-8
Command-Specific Response Codes
Code
0
1 - 2
3
Format
0 – Range 3.5 mA – 20 mA, 1 -- Range 1.25 – 20 mA
Format
0 – Range 3.5 mA – 20 mA, 1 -- Range 1.25 – 20 mA
Class
Success
No Command-Specific Errors
Undefined
Error
Passed Parameter Too Large
Undefined
Error
Too Few Data Bytes Received
Undefined
Format
0 – Classic Mode, 1 – Enhance Mode
Format
0 – Classic Mode, 1 – Enhance Mode
Class
Success
No Command-Specific Errors
Undefined
Error
Passed Parameter Too Large
Description
Description
Description
Description
Description
Description
25
OBSERVER-i HART
