10.25 COMMAND #172: SET ENHANCE MODE AO

This command sets the Analog output in Enhance Mode.
Request Data Bytes
Byte
0 Unsigned-8
Response Data Bytes
Byte
0 Unsigned-8
Command-Specific Response Codes
Code
0
1 - 2
3
4
5
6 - 127
Class
Undefined
Error Too Few Data Bytes Received
Undefined
Format
1 – Discrete SPL (4-12mA for 40-120dB, 16mA for Warn, 20mA
for Alarm)
2 – Discrete (4mA Stand by, 16mA for Warn and 20mA for Alarm)
3 – Full SPL (4 - 20mA for 40 to 120dB)
Format
1 – Discrete SPL (4-12mA for 40-120dB, 16mA for Warn, 20mA
for Alarm)
2 – Discrete (4mA Stand by, 16mA for Warn and 20mA for Alarm)
3 – Full SPL (4 - 20mA for 40 to 120dB)
Class
Success No Command-Specific Errors
Undefined
Error Passed Parameter Too Large
Undefined
Error Too Few Data Bytes Received
Undefined
Description
Description
Description
Description
26
OBSERVER-i HART
