10.4 COMMAND #141: SET ALARM RELAY CONFIGURATION

This command configures the relay settings.
Request Data Bytes
Byte
0 Unsigned-8
1 Unsigned-8
Response Data Bytes
Byte
0 Unsigned-8
1 Unsigned-8
Command-Specific Response Codes
Code
0 Success
1 - 2
3 Error
4
5 Error
16 Error
17 – 127

10.5 COMMAND #142 RESET EVENT HAPPENED FLAG

This command resets the Event Happened Flag.
Request Data Bytes
Byte
None N/A
Response Data Bytes
Byte
None N/A
Format
Alarm Hi Relay La/nL: 0 – nL, 1 – LA
Alarm Hi Relay En/dE: 0 – dE, 1 – En
Format
Alarm Hi Relay La/nL: 0 – nL, 1 – LA
Alarm Hi Relay En/dE: 0 – dE, 1 – En
Class
No Command-Specific Errors
Undefined
Passed Parameter too large
Undefined
Too Few Data Bytes Received
Access Restricted
Undefined
Format
N/A
Format
N/A
Description
Description
Description
Description
Description
