Trove2R Enclosure Dimensions:
3.375" x 19.0" x 33.25" (85.8mm x 482.6mm x 844.6mm). Shown with Z Bracket attached.
1.5"
(38.1mm)
0.72"
(18.3mm)
15.14" (384.4mm)
15.05" (382.3mm)
0.63" (16mm)
0.52" (13.2mm)
4.5" (114.3mm)
11.2" (284.5mm)
Altronix is not responsible for any typographical errors.
––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com
MEMBER
IITrove2R
J05V
- 8 -
Trove2R Installation Guide
