Altronix TROVE Series Installation Manual page 6

UL Listed Altronix Power Supplies and Sub-Assemblies:
Altronix UL Listed
Power Supply
AL400ULXB2
AL600ULXB
AL1012ULXB
AL1024ULXB2
A
eFlow4NB
eFlow6NB
eFlow102NB
eFlow104NB
Altronix UL Listed
Sub-Assembly
LINQ8ACM(CB)
ACM8(CB)
B
ACMS8(CB)
ACMS12(CB)*
PDS8(CB)
PDS16(CB)*
ACM4(CB)
MOM5
C
VR6
PD4UL(CB)
PD8UL(CB)
* These modules have not been evaluated by UL.
Compatible Hirsch Controllers and Sub-Assemblies**
Hirsch Board
Mx-28-SBOB
RREB
AEB8
REB8
** To mount the above Hirsch Controllers and Sub-Assemblies you must utilize THR2R backplane.
- 6 -
Power Supply Specifications:
Input Rating
115VAC, 60Hz, 3.5A
115VAC, 60Hz, 3.5A
115VAC, 60Hz, 2.6A
115VAC, 60Hz, 4.2A
120VAC, 60Hz, 3.5A
120VAC, 60Hz, 3.5A
120VAC, 60Hz, 3.5A
120VAC, 60Hz, 4.5A
Sub-Assembly Specifications:
Description
8 Fused (or PTC) Output
Networked Access Power Controller
8 Fused (or PTC) Output
Access Power Controller
8 Fused (or PTC) Output
Access Power Controller
8 Fused (or PTC) Output
Access Power Controller
8 Fused (or PTC) Output
Power Distribution Module
16 Fused (or PTC) Output
Power Distribution Module
4 Fused (or PTC) Output
Access Power Controller
5 PTC Output Power Distribution
Module with Fire Alarm Interface
Voltage Regulator
4 Fused (or PTC) Output
Power Distribution Module
8 Fused (or PTC) Output
Power Distribution Module
Output Rating
12VDC @ 4A or 24VDC @ 3A
12VDC or 24VDC @ 6A
12VDC @ 10A
24VDC @ 10A
12VDC or 24VDC @ 4A
12VDC or 24VDC @ 6A
12VDC @ 10A
24VDC @ 10A
Current Draw
12VDC @ 0.6A max. or
24VDC @ 0.3A max.
12VDC @ 0.6A max. or
24VDC @ 0.3A max.
12VDC @ 0.6A max. or
24VDC @ 0.3A max.
12VDC @ 0.6A max. or
24VDC @ 0.3A max.
N/A
N/A
12VDC @ 0.4A max. or
24VDC @ 0.2A max.
12-24VDC 55mA max.
24VDC @ 1.75A or 3.5A
Output: 5VDC or 12VDC @ 6A
N/A
N/A
Description
High-Security Access Controller
Reader Expansion Board
Access Expansion Board
Relay Expansion Board
Battery Size for
30 min. Backup
4AH
7AH
ULXB Installation Guide
Rev. ULXB-020419
12AH
12AH
4AH
7AH
eFlow Installation Guide
Rev. EFNB-021319
12AH
12AH
Refer to
LINQ8ACM Installation Guide
Rev. 100219
ACM8/ACM8CB Installation Guide
Rev. 031819
ACMS8/ACMS8CB Installation
Guide Rev. 090518
ACMS12/ACMS12CB Installation
Guide Rev. 061622
PDS8/PDS8CB Installation Guide
Rev. 070116
PDS16/PDS16CB Installation
Guide Rev. 060822
ACM4/ACM4CB Installation Guide
Rev. 052819
MOM5 Installation Guide
Rev. 020119
VR6 Installation Guide
Rev. 050517
PD4UL Installation Guide
Rev. 020119
PD4ULCB Installation Guide
Rev. 020119
PD8UL Installation Guide
Rev. 020119
PD8ULCB Installation Guide
Rev. 020119
Trove2R Installation Guide
Refer to
