Access & Power Integration
Altronix/AMAG M4000 Kits
Models Include:
T2AGK3F8V
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow6NBV - Power Supply/Charger
- One (1) ACM8 - Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T2AGK7F8SV
8 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NBV - Power Supply/Charger
- One (1) ACMS8 - Dual Input Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T2AGK7F12V
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NBV - Power Supply/Charger
- One (1) ACM8 - Fused Access Power Controller
- One (1) ACM4 - Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Module
T2AGK7F12SV
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NBV - Power Supply/Charger
- One (1) ACMS8 - Dual Input Fused Access Power Controller
- One (1) ACM4 - Fused Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8 - Dual Input Fused Power Distribution Modulee
T2AGK75F12V
12 Door Kit with Fused Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NBV - Power Supply/Charger
- One (1) eFlow102NBV - Power Supply/Charger
- One (1) ACM8 - Fused Access Power Controller
- One (1) ACM4 - Fused Access Power Controller
- One (1) PD4UL - Fused Power Distribution Module
Installation Guide
All registered trademarks are property of their respective owners.
Rev. TAGKV_121924
Installing Company: _________________________ Service Rep. Name: __________________________________________
Address: _________________________________________________________ Phone #: _________________________
T2AGK3F8DV
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow6NBV - Power Supply/Charger
- One (1) ACM8CB - PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T2AGK7F8SDV
8 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NBV - Power Supply/Charger
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T2AGK7F12DV
12 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NBV - Power Supply/Charger
- One (1) ACM8CB - PTC Access Power Controller
- One (1) ACM4CB - PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Module
T2AGK7F12SDV
12 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NBV - Power Supply/Charger
- One (1) ACMS8CB - Dual Input PTC Access Power Controller
- One (1) ACM4CB - PTC Access Power Controller
- One (1) VR6 - Voltage Regulator
- One (1) PDS8CB - Dual Input PTC Power Distribution Modulee
T2AGK75F12DV
12 Door Kit with PTC Outputs
Fully assembled kit includes:
- Trove2 enclosure with TAM2 Altronix/AMAG backplane
- One (1) eFlow104NBV - Power Supply/Charger
- One (1) eFlow102NBV - Power Supply/Charger
- One (1) ACM8CB - PTC Access Power Controller
- One (1) ACM4CB - PTC Access Power Controller
- One (1) PD4ULCB - PTC Power Distribution Module
More than just power.™
