Access & Power Integration
THWD2
- Honeywell ProWatch/WinPak door backplane for Trove2 and Trove3
Installation Guide
THWD2 accommodates a variety of Honeywell ProWatch/WinPak boards for access systems of up to twelve (12) doors.
• 16 Gauge backplane.
Dimensions (H x W x D): 23.75" x 18.125" x 0.3125" (603.3mm x 460.3mm x 7.9mm).
Backplane Accommodates a Combination of the Following:
• Up to six (6) PRO32IC, PRO32R2, PRO32IN, PRO32OUT, PW6K1IC, PW6K1R2, PW6K1IN, PW6K1OUT modules.
• One (1) PRO22MX8 module.
Nylon Standoff |
Overview:
Specifications:
Hardware:
5/16" Pan Head Screw |
Lock Nut
THWD2_Rev. 122418
Advertisement
Table of Contents
Related Manuals for Altronix Trove THWD2
Summary of Contents for Altronix Trove THWD2
- Page 1 THWD2_Rev. 122418 Access & Power Integration THWD2 - Honeywell ProWatch/WinPak door backplane for Trove2 and Trove3 Installation Guide Overview: THWD2 accommodates a variety of Honeywell ProWatch/WinPak boards for access systems of up to twelve (12) doors. Specifications: • 16 Gauge backplane. Dimensions (H x W x D): 23.75”...
- Page 2 THWD2: Configuration of Honeywell ProWatch/WinPak Boards: Honeywell ProWatch/WinPak Access Controllers: 1. Fasten standoffs (provided) into pem configuration (A) or (B) of backplane (Fig. 1, pg. 2). 2. Mount boards to standoffs utilizing 5/16” pan head screws (provided) (Fig. 1a, pg. 2). 3.
- Page 3 Notes: THWD2 - Honeywell ProWatch/WinPak Door Backplane - 3 -...
- Page 4 13.7” (350mm) Altronix is not responsible for any typographical errors. 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 web site: www.altronix.com | e-mail: info@altronix.com | Made in U.S.A. IITHWD2 A16S MEMBER - 4 -...
