Danfoss VACON NXP Design Manual page 19

DC Filters
Design Guide
Code Num- Filter type code
ber
181B5959 LDC-0030-6-0-ATr
181B5960 LDC-0050-6-0-APt
181B5961 LDC-0050-6-0-ATr
181B5962 LDC-0092-5-0-APt
181B5963 LDC-0092-5-0-ATr
181B5966 LDC-0092-6-0-APt
181B5967 LDC-0092-6-0-ATr
181B5964 LDC-0092-5-0-BPt
181B5965 LDC-0092-5-0-BTr
181B5970 LDC-0170-6-0-APt
181B5971 LDC-0170-6-0-ATr
181B5972 LDC-0270-5-0-APt
181B5973 LDC-0270-5-0-ATr
181B5976 LDC-0400-6-0-APt
181B5977 LDC-0400-6-0-ATr
181B5978 LDC-0400-6-0-BPt
181B5979 LDC-0400-6-0-BTr
181B5980 LDC-0420-5-0-APt
181B5981 LDC-0420-5-0-ATr
181B5982 LDC-0540-6-0-BPt
181B5983 LDC-0540-6-0-BTr
181B5986 LDC-0900-5-0-BPt
181B5987 LDC-0900-5-0-BTr
Danfoss A/S © 2023.01
Manufacturer part Rated
code voltage
[V DC]
56606-SET-THER-
MIK
36326-SET-PT100 1025
36326-SET-THER-
MIK
36327-SET-PT100 750
36327-SET-THER-
MIK
56771-SET-PT100 1025
56771-SET-THER-
MIK
36584-SET-PT100 750
36584-SET-THER-
MIK
37404-SET-PT100 1025
37404-SET-THER-
MIK
38739-SET-PT100 750
38739-SET-THER-
MIK
38331-SET-PT100 1025
38331-SET-THER-
MIK
38349-SET-PT100 1025
38349-SET-THER-
MIK
39023-SET-PT100 750
39023-SET-THER-
MIK
44079-SET-PT100 1025
44079-SET-THER-
MIK
53552-SET-PT100 750
53552-SET-THER-
MIK
Cooling Nominal Power
current loss at
at 50 °C 20 °C
[A] [W]
AN 50 250
AN 92 340
AN 92 330
AF 92 300
AN 170 450
AN 270 460
AN 400 840
AF 400 1100
AN 420 750
AF 540 1300
AF 900 1900
AJ377845348678en-000101 / 172F4785 | 19
Specifications
Protec- Switching
tion frequency
rating [kHz]
IP00 5
IP00 5
IP00 5
IP00 5
IP00 5
IP00 5
IP00 5
IP00 5
IP00 5
IP00 5
IP00 5
