GEA VARIVENT TSVN Operating Instruction page 43

Item Designation
1 Seal ring
2 Bearing
Bearing, 3A
3 Sealing washer I
5 O-ring
7 V-ring
8 Sampling housing N-1, 1
connectors
Sampling housing N-2, 2
connectors
9 Sampling lantern
10 Square ring
15 Valve disk N
16 Piston rod
17.1 Piston
18 Spring cage cover
19 Compression spring
20 Handwheel
21 Contact disk
22 O-ring
23 O-ring
24 Quad ring
26 Screw-in plug connection G 1/8''
-6/4
Screw-in plug connection G 1/8''
-6.35/4.31
27 Lock washer
28 Hinged clamp
33 Guide ring
34 Bush
35 Vent screw
DN 25
DN 40
DN 50
DN 65
DN 80
A
DN 100
DN 125
1'' OD
1.5'' OD
430BAL008565EN_1
21.03.2022
Material
EPDM
FKM
PTFE/carbon
SUSTA-PVDF
1.4404
EPDM
FKM
EPDM
FKM
1.4404
1.4404
1.4404
1.4571 K
1.4404
1.4460
3.2315.72
EN AW-6082 T6
1.4310
PPH 4150
1.4301
NBR
NBR
NBR
Ms CV
Ms CV
1.4122
1.4404
Turcite-T51
1.4301
PP
Used in combination with a VARIVENT housing, 2 sockets
1.4404
1.4404
1.4404
1.4404
1.4404
1.4404
1.4404
1.4404
1.4404
Spare parts list - Sampling valve TSVN"
DN 25 DN 32
924-255 924-255
924-297 924-297
935-037 935-037
935-097 935-097
222-601.01 222-601.01
930-309 930-309
930-168 930-168
932-064 932-064
932-073 932-073
229-330.05 229-330.05
229-330.01 229-330.01
229-336.02 229-336.02
221-313.01 221-313.01
229-331.05 229-331.05
229-336.04 229-336.04
229-332.04 229-332.04
229-332.07 229-332.07
931-258 931-258
229-332.08 229-332.08
229-336.01 229-336.01
930-052 930-052
930-605 930-605
930-466 930-466
933-176 933-176
933-173 933-173
917-119 917-119
701-074 701-074
935-038 935-038
229-332.10 229-332.10
221-133.14 221-133.14
221-102.41 221-102.41
-- --
-- --
-- --
-- --
-- --
-- --
221-102.52 221-102.52
-- --
DN 40 DN 50
924-255 924-255
924-297 924-297
935-037 935-037
935-097 935-097
222-601.01 222-601.01
930-309 930-309
930-168 930-168
932-064 932-064
932-073 932-073
229-330.06 229-330.06
229-330.02 229-330.02
229-336.02 229-336.02
221-313.01 221-313.01
229-331.04 229-331.04
229-336.04 229-336.04
229-332.04 229-332.04
229-332.07 229-332.07
931-258 931-258
229-332.08 229-332.08
229-336.01 229-336.01
930-052 930-052
930-605 930-605
930-466 930-466
933-176 933-176
933-173 933-173
917-119 917-119
701-074 701-074
935-038 935-038
229-332.10 229-332.10
221-133.14 221-133.14
-- --
221-102.43 221-102.43
221-102.44 221-102.44
221-102.23 221-102.23
221-102.24 221-102.24
221-102.18 221-102.18
221-102.21 221-102.21
-- --
221-102.53 221-102.53
