Spectre Integra-M/MA Assembly Manual

Introduction

Spectre Integra-M Dark
Spectre Integra-M Dark has a space theme with aesthetics inspired by fighter jets and spacecraft.
It has a 3-layer distribution plate where Spectre Integra-M which has a 2-layer distribution plate
built from clear acrylic. Spectre Integra-M Dark has a clear acrylic cover and motherboard tray,
the main distribution plate layer is grey tinted acrylic, the rear distribution plate layer is clear
acrylic, and the rear cover is satin black acrylic. The reservoir volume is much larger allowing for
easier filling and bleeding, and increased flow.
Spectre Integra-M
Spectre Integra-M is a more compact ATX version of Spectre. It is a full re-design using everything
we have learned from the development of Spectre which has continued since 2015. Integra-M is
25% smaller than Spectre 3.0 (all versions) but maintains all the features, except that it fits ATX
motherboards and two 360mm radiators which are 40mm thick. Integra-M has a large part of the
water-cooling loop integrated with a completely new distribution plate design. It has a fully
integrated solution for cables with the Singularity Computers PowerBoard. Previously we have
created PowerBoards for existing cases, but for Integra-M we have developed the PowerBoard
and case together. This means that both have become far more streamlined, meaning more
features and compatibility. The PowerBoard supports the most high-end components and
includes two of the new 12VHPWR connectors along with x3 8pin PCIE connectors. It has built in
filter capacitors, 24 integrated ARGB and UV LEDs facing inwards and outwards, integrated direct
connect SATA, power, and reset buttons, and a touch activated power button. There is no rear
access needed to the case for cable management, all cables can be connected from the front and
little to no cable management is needed. Black sleeved linking cables are included with the case.
Custom colored sleeved linking cables can be purchased separately.
Spectre Integra-MA
Integra-MA does not include a distribution plate but includes a PowerBoard. It is capable of
housing a high-end liquid cooled system with two 360mm radiators, the top one up to 40mm thick
and the front one up to 60mm thick. The Singularity Computers PowerBoard is an integrated
solution for cables, lighting and much more. Previously we have created PowerBoards for existing
cases, but for Integra we have developed the PowerBoard and case together. This means that
both have become far more streamlined, meaning more features and compatibility. The
PowerBoard supports the most high-end components and includes two of the new 12VHPWR
connectors. The PowerBoard has built in filter capacitors, 24 integrated ARGB and UV LEDs facing
inwards and outwards, integrated direct connect SATA, power, and reset buttons, and a touch
activated power button. There is no rear access needed to the case for cable management, all
cables can be connected from the front and little to no cable management is needed. Black
sleeved linking cables are included with the case. Custom colored sleeved linking cables can be
purchased separately.
