Introduction

Stream-S is an SFF case designed for high end water-cooling. It has a distribution plate on the
front panel which integrates a pump and reservoir. It fits x2 240mm radiators, a full-sized GPU
and 2x 2.5" drives. Stream-S is the first case which does not need wires for the main cables. It has
a PowerBoard which connects directly to the PSU and includes flexible PCBs which connect the
PowerBoard to the motherboard and GPU. The PowerBoard and flexible PCBs remove the need
for cable management and make the cables extremely clean and compact which is particularly
important for an SFF case.
Specifications & Included Items
Water-cooling Integration
Electronics Integration
Cables
Motherboard Form Factor
Expansion Slots
Case Form Factor
Case Dimensions & Weight
Package Dimensions & Weight
Storage
Radiators
Max. GPU Length
Max. GPU Height
Max. CPU Cooler Height
Max. PSU Length
Front Panel I/O
Vertical GPU Mount
Materials
Manufacturing Process
Assembly
Testing/Validation
V0.1
Reservoir, Pump Top, Pump Cover, Fill Port, Drain Port, Parts of water-
cooling loop.
Ports: x6 G1/4" BSPP, 1x Fill Port, 1x Drain Port
Pump (Not included): Compatible with all DDC pumps.
Core Component Connectors: 24pin x1, 8pin EPS x1, PCIE 8pin x3, 12VHPWR
x1, 6pin PSU x2.
Hubs: PWM x4, ARGB x5 (Single input for all).
Extra Power Button.
Built-in PSU Jump starter for powering the pump only, for filling the loop.
PowerBoard Linking FPC Cables: 24pin x1. 8pin EPS x1. Select either 8pin PCIE
x3 or 12VHPWR (non FPC) Cable.
PWM Female to Female 50cm Black Sleeved x1.
ARGB Female to Female 50cm Black Sleeved x1.
LED Strips: x3 Installed on the Distribution Plate, the Motherboard Tray, and
the Top Panel.
Mini-ITX.
x2.
SFF.
L: 346mm W: 165mm H: 381mm | 6kg
L: 406mm H: 225mm W: 441mm. (Case comes fully assembled) | 6.5kg
2x 2.5".
40mm x 30mm w/ x1 set of standard 25mm fans.
323mm.
Unlimited.
138mm.
Compatible only with the Asus ROG Loki series.
n/a | Touch activated button.
x1 2 slot. PCIe 4.0 Vertical GPU Riser Cable 20cm.
061 Aluminum Anodized, Cast Acrylic, Stainless Steel, PCB.
CNC Mill, CNC Lathe, CNC Router, Aluminium Folding, PCB.
Distribution Plate Assembled by Hand. Metal Components need to be
assembled and attached to the distribution plate by the customer.
All Distribution Plates are factory pressure tested and precise fastener
tension is applied.
