Spectre Integra-M/MA Features

Integrated Liquid Cooling Features (Integra-M only)
•
Reservoir, D5 Pump Top, D5 Pump Cover, Fill Port, Drain Port, parts of the cooling loop.
PowerBoard Integration
•
The PowerBoard is a PCB integrating 24pin, EPS, PCIE and 12VHPWR along with PWM and ARGB
Hubs, SATA and Power and Reset Buttons. The Spectre Integra-M PowerBoard also has an
integrated touch sensing Power Button. The PowerBoard has x24 ARGB and UV LEDs
positioned around the external and internal perimeter to optimally light up the distribution
plate. The LEDs can be switched on or off and you can switch between ARGB or UV or have both
on at the same time. Essentially the PowerBoard is a distribution plate for cables also
integrating other features and functions. It is a new method for cables allowing
standardization of cable lengths and making cable management almost unnecessary. Spectre
Integra-M comes included with a standard set of black sleeved linking cables including 24pin
x1, 8pin EPS x2, 8pin PCIE x3 meaning that these cables don't have to be purchased separately.
Reduced build time due to integration
•
With the core component cables, PWM and ARGB hubs all integrated there is less assembly to
be done, there is almost no cable management thanks to the PowerBoard integration. Even
further build time reduction on Integra-M with the pump, reservoir, fill & drain ports and parts
of the water-cooling loop are integrated.
Integration Cost Component
•
A large portion of the case cost is due to the integration. These are components you do not
have to purchase for your build. The pump, reservoir, cables, hubs, less fittings, less tube, no
lighting, no cable combs, or cable management components. Integra-M reduces cost further
on water-cooling components.
Integration & Optimization
•
With the integration we did not just develop a case, we also developed all the integrated
components. This meant that we could focus more on optimization than would normally be
possible. The integrated loop routes in Spectre Integra-M allow for more flow than 16mm
tubes. The pump top was designed for the D5 pump, maximizing flow to and from the
distribution plate. The reservoir was designed to remove air as quickly as possible making the
loop easier to fill. The fill port is at the highest point on the back for the case and the drain point
at the lowest point.
