5 — TA B L E F R A M E A S S E M B LY
5.1
Place the fully assembled beams on the
Base Assembly, seating the channel of the
extrusion in to the U Channel of the base.
Note: leave the Kickstands in place
until the beams are fully secured.
5.3
Secure the ends of both extrusion to the Base
Assemblies using a .375-16 x 1.25" bolt, then proceed to
secure the extrusion with the using .375-16 x 2.25" bolts.
Repeat process for the other end of the table.
TI0075 - Expanse Table Installation Instructions
5.2
Align the holes of the assembled beams to
the holes of the assembled bases.
5.4
Slide the extrusions completely until the
surfaces meet. The C Channel holes should
alight with the top slots on the middle
extrusion assembly as shown below.
