- Page 1 Expanse 96"–144" Installation Guide TI0089 - Expanse 96"–144" Installation Guide – Rev 07.26.24...
-
Page 2: Tools And Supplies Required
TOOLS & SUPPLIES REQUIRED DRILL PHILLIPS HEAD DRIVER LEVEL RATCHET SOCKET TAPE MEASURE TI0089 - Expanse 96"–144" Installation Guide... - Page 3 #10-24 X .50 PHILLIPS PAN HEAD .25-20 HEX FLANGE NUT LIPS (SCREW 1) .375-16 EASY ADJUST LEVELER MAGNET PDGR CABLE MANAGER FELT STRIP ANGLE BRACKET TIGHT JOINT CONNECTOR WOOD BISCUIT FRONT COVER TOP COVER BEAM BASE TI0089 - Expanse 96"–144" Installation Guide...
-
Page 4: Base Assembly
FIG 1.4 (ANGLE BRACKETS ATTACHMENT) Attach Beams to Bases via .375-16 x 2.25 Hex Head Bolts. Attach Angle Brackets to Base Assembly via #10-24 x .50 Phillips Pan Head Screws. Note: Predrilled holes must be inward facing. TI0089 - Expanse 96"–144" Installation Guide... -
Page 5: Top Assembly
Connect Top via Tight Joint Connectors, then center the Top on the Base Assembly. Attach the Base to the Top via 10-10 x 1“ Truss Head (Screw 1) screws. FIG 2.2 (TABLE LEVELING) Level table via Easy Adjust Levelers. Installation is now complete. TI0089 - Expanse 96"–144" Installation Guide... - Page 6 800.815.7251 enwork.com 12900 Christopher Drive Lowell, MI 49331 Specifications subject to change without notice.
