Enwork Expanse Installation Manual page 5

3 — B A S E A S S E M B LY
3.1
Assemble (4)Glides into the Baseplate.
Assemble the Inside Base Bottom
Cover using (3) 25-20 Nuts.
2x
3.3
While standing on the base plate, Line up the connection
holes of the Top Plate Assembly with the Base Leg
assembly and attach using (8).375-16 x 1.25" bolts.
Note: Once the base is full assembled, place the provided
Kickstand under the assembly to keep it from falling forward.
2x
TI0075 - Expanse Table Installation Instructions
3.2
Line up the Base Leg connection holes
with the holes on the Base Plate. Secure
together with (4).375-16 x 1.25" bolts.
Note: The angles cut into the attachment
plates should be facing the back.
2x
3.4
When the base assemblies are completed,
place them in there final position.
5
