Component References; Table 5. Mandatory Components; Table 6. Optional Components - ST STM32F10 Series Application Note

Reference design
7.2

Component references

Id
1 Microcontroller STM32F103ZE(T6)
2 Capacitors
3 Capacitor
Id
1 Resistor
2 Resistor
3 Resistor
4 Capacitor
5 Capacitor
6 Capacitor
7 Capacitor
8 Quartz
9 Quartz
10 JTAG connector
11 Battery
12 Switch
13 Push-button
24/29

Table 5. Mandatory components

Name Reference
100 nF
10 µF

Table 6. Optional components

Name Reference
10 kΩ
390 Ω
0 Ω
100 nF
1µF
10 pF
20 pF
8 MHz
32 kHz
HE10
3V3
3V3
B1
Quantity
1 144-pin package
11 Ceramic capacitors (decoupling capacitors)
1 Ceramic capacitor (decoupling capacitor)
Quantity
5 Pull-up and pull-down for JTAG and Boot mode.
Used for HSE: the value depends on the crystal
characteristics.
1
This resistor value is given only as a typical
example.
Used for LSE: the value depends on the crystal
characteristics.
1
This resistor value is given only as a typical
example.
3 Ceramic capacitor
2 Used for VDDA and VREF.
Used for LSE: the value depends on the crystal
2
characteristics.
Used for HSE: the value depends on the crystal
2
characteristics.
1 Used for HSE
1 Used for LSE
1
If no external battery is used in the application, it is
1
recommended to connect V
2 Used to select the correct boot mode.
1
AN2586 Rev 8
Comments
Comments
-
externally to V
BAT
-
DD
