Component References; Table 4. Mandatory Components; Table 5. Optional Components - ST STM32C0 Series Getting Started

6.2

Component references

Component
Microcontroller
Capacitor
Capacitor
Component
Resistor
Capacitor
Capacitor
Capacitor
Capacitor
Quartz
Quartz
Push-button
SWD connector
AN5673 - Rev 2
Table 4. Mandatory components
Reference Value
U1 STM32C031CxT
C1 100 nF
C6 4.7 μF
Table 5. Optional components
Reference Value
R1 390 Ω
C4 100 nF
C5 100 nF
C7/C8 10 pF
C9/C10 20 pF
X1 8 MHz
X2 32 kHz
B1 -
CN1 FTSH-105-01-L-DV
Component references
Quantity Comments
1 48-pin package
1 Ceramic capacitors (for decoupling)
1 Used for VDD
Quantity Comments
Used for HSE, the value depends on
1
the crystal characteristics
1 Ceramic capacitor for RESET button
1 Ceramic capacitors (for decoupling)
Used for LSE, the value depends on
2
the crystal characteristics
Used for HSE, the value depends on
2
the crystal characteristics
1 Used for HSE
1 Used for LSE
1 Used as reset button
1 Used for program/debug
