Power supplies
2.3.2

Programmable voltage detector (PVD)

You can use the PVD to monitor the V
selected by the PLS[2:0] bits in the Power control register (PWR_CR).
The PVD is enabled by setting the PVDE bit.
A PVDO flag is available, in the Power control/status register (PWR_CSR), to indicate
whether V
EXTI Line16 and can generate an interrupt if enabled through the EXTI registers. The PVD
output interrupt can be generated when V
V
rises above the PVD threshold depending on the EXTI Line16 rising/falling edge
DD
configuration. As an example the service routine can perform emergency shutdown tasks.
PVD output
2.3.3

System reset

A system reset sets all registers to their reset values except for the reset flags in the clock
controller CSR register and the registers in the Backup domain (see
A system reset is generated when one of the following events occurs:
1.
A low level on the NRST pin (external reset)
2.
Window watchdog end-of-count condition (WWDG reset)
3.
Independent watchdog end-of-count condition (IWDG reset)
4.
A software reset (SW reset)
5.
Low-power management reset
The reset source can be identified by checking the reset flags in the Control/Status register,
RCC_CSR.
10/29
is higher or lower than the PVD threshold. This event is internally connected to
DD
power supply by comparing it to a threshold
DD
drops below the PVD threshold and/or when
DD

Figure 4. PVD thresholds

PVD threshold
AN2586 Rev 8
100 mV
hysteresis
MS30432V2
Figure
1).
