Service guide | Disassembling and assembling MAH 6.3 - 12.5
Flange
Pistons
Port plate
Retaining plate
O-rings
Pins
6
18. Parts
Thrust plate with sealing
Screws and washers
180R9152 | AX357937856579en-000402 | 07.2021
Swash plate
Housing
Shaft seal
Washer
Cylinder barrel
Retaining
guide
Front cover
Pins and springs
Seal
Spring
