Service guide | Disassembling and assembling MAH 6.3 - 12.5
Table of Contents
Introduction
2
Introduction .......................................................................................................................................... 2
1. Disassembling the motor ................................................................................................................. 3
2. Inspection .............................................................................................................................................. 7
3. Assembling the motor ........................................................................................................................ 8
4. Service kit for MAH 6.3 ..................................................................................................................... 13
4.1. Service kit for MAH 12.5 ................................................................................................................... 14
5. Exploeded view MAH 6.3 ................................................................................................................ 15
5.1. Exploded view 12.5 ........................................................................................................................... 16
NOTE: If the motor is disassembled within the warranty period, the motor is no longer covered
by the warranty.
This document covers the instructions for
disassembling and assembling the motor
MAH 6.3 - 12.5
Tools needed for disassembling/assembling the MAH 6.3 - 12.5 motor
