Service guide | Disassembling and assembling MAH 6.3 - 12.5
13 Remove O-ring from flange..
15. Loosen thrust plate using a screwdriver.
Place screwdriver in slot of thrust plate.
17. Wash all parts and replace all seals
(inclusive shaft seal).
Inspect all parts carefully (see "Inspection")
and replace any worn parts.
If the motor has failed, the reason for the
failure must be found and fi xed before the
repaired motor is re-installed.
180R9152 | AX357937856579en-000402 | 07.2021
14. Remove O-ring from port.
16. Remove swash plate from housing.
