- Page 1 INSTRUCTION MANUAL AIR 23 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future reference. Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled. Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 45MIN. ASSEMBLY HARDWARE M3.5x40mm SCREW M6.0x50mm BOLT 4PCS+1spare 24PCS+1spare M3.5x35mm SCREW M3.5x50mm SCREW 8PCS+1spare 12PCS+1spare M3.0x16mm SCREW M3.5x25mm SCREW 4PCS+1spare 8PCS+1spare Spring latch 2PCS... - Page 5 PARTS Left panel of coop Back panel of coop - Front panel of coop - Upper Upper Right panel of coop Left panel of nest box Right panel of nest box Bottom panel of nest box Front panel of nest box Front panel of pen - Down...
- Page 6 PARTS Side panel of pen - Down Plastic tray Back panel of pen - Down Perch Front panel of side pen Back panel of side pen Side panel of side pen Roof of coop Roof of nest box 2PCS...
- Page 7 PARTS Roof cap Roof of side pen Ramp...
-
Page 9: Product Assembly
PRODUCT ASSEMBLY ① Ensure screw holes on long side of “I1” and “I2” are oriented at top. ② Ensure that all pen - panels have stapled-wire facing inside. ③ All dowels on “K” with hole on “I1” and “I2” by screw 4xP2. ④ Ensure all corner line up before screwing together . Screw Holes This area is part of the ① Align dowels on “A”... - Page 10 PRODUCT ASSEMBLY ① Insert “L” piece into slots inside “C” and “D”. ② Slide “J” into bottom slot of Coop. Bolt “E’’ and “F” to Coop by 4xP1. ① ② Screw “H” to “E’’ and “F” by 4xP4.
- Page 11 PRODUCT ASSEMBLY ① Drop in Nest Box floor “G”. ② Screw ladder R into bottom half of lower panel on D by 4xP6, so as not to interfere with sliding door. Screw roof panels “O” to the Coop by 8XP4.
- Page 12 PRODUCT ASSEMBLY Ensure top roof panels line up with each other before screwing ① “S” by 4xP5. Ensuring the latch with lock on “H” before attach nest box lid at ② the hinges. Connect the Pen to the Coop by 4XP3 on each side.
- Page 13 PRODUCT ASSEMBLY Align dowels on “N” with holes on “M1” and “M2” by 4xP2. This area is a part of the Pen Complete the side pen by screwing the top roof Part Q to the front & back Part M1, M2 ,side Part N by 4xP2.
- Page 14 PRODUCT ASSEMBLY Screw the spring latch by 4xP6, please pay attention to the direction. Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this product.
