- Page 1 NSTRUCTION MANUAL AIR45 www.aivituvin.com...
- Page 2 NOTICE Please retain these instructions for future Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled.
-
Page 3: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 60MIN. ASSEMBLY HARDWARE M6.0x50 mm BOLT M4.0x40 mm SCREW 8PCS+1 spare 24PCS+1 spare M3.5x60 mm SCREW M3.5x35 mm SCREW 8PCS+1 spare 8PCS+1 spare M3.5x25 mm SCREW M3.0x16 mm SCREW 6PCS+1 spare 32PCS+1 spare Latch Hinge... - Page 4 HARDWARE Lock Coop Nesting box...
- Page 5 PARTS CARTON 1/2 Front panel Back panel Left panel Right panel Tray Perch 2PCS Divider of nesting box Roof of nesting box Roof of coop 2PCS 2PCS...
- Page 6 PARTS CARTON 2/2 Left panel of nesting box Front panel of nesting box Right panel of nesting box 2PCS 2PCS 2PCS Bottom of nesting box Bottom plate Left pen panel (close to the hutch) 2PCS Right pen panel Left pen panel Right pen panel (outside) (close to the hutch)
- Page 7 PARTS Side panel of pen Roof of pen PVC Waterproof Strip 2PCS 2PCS Hardware bag...
-
Page 8: Product Assembly
PRODUCT ASSEMBLY Attach the front & back panel Part A & B to the side panel Part C & D by 8xP2. ① Slide in the metal tray Part E. ② Insert the perch Part F into the slots inside the front and back panel. - Page 9 PRODUCT ASSEMBLY Attach the side panels of nesting box Part G1 & G2 to the left side of coop by bolt 4xP1. Attach the side panels of nesting box Part G1 & G2 to the right side of coop by bolt 4xP1.
- Page 10 PRODUCT ASSEMBLY Screw the side panel of nesting box to the front panel of nesting box Part H by 4xP2 each side. ① Drop in the bottom of nesting box Part I. ② Slide in the divider Part J.
- Page 11 PRODUCT ASSEMBLY ① Make sure the lock is functioning properly before locking the roof. ② Attach the nesting box roof Part K to the nesting box by 4xP6 each side. Attached PVC Waterproof Strip Part T to the nesting box by 3XP5 each.
- Page 12 PRODUCT ASSEMBLY Attach the coop roof Part L to the coop by 6xP6. Attach the lock P9 to the tray by 6XP6.
- Page 13 PRODUCT ASSEMBLY ① Attach the roof hinge P8 to the coop by 4XP6 each side. ② Attach the pen panel Part N&O to the coop by 4XP3. Attach the bottom baffle Part M to the side by 4xP2.
- Page 14 PRODUCT ASSEMBLY Attach Part P & Q by 4xP3. Attach the side panel Part R to the pen by 4xP2.
- Page 15 PRODUCT ASSEMBLY Attach the pen roof Part S to the pen by 8xP4. Attach the latch P7 to the side by 4xP6. Finish...
- Page 16 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this...
