Summary of Contents for aivituvin AIR46
- Page 1 NSTRUCTION MANUAL AIR46 www.aivituvin.com...
- Page 3 NOTICE Please retain these instructions for future Firmly secure all bolts,screws and knobs before use. Reconfirm that all bolts,screws,and knobs are secure every 90 days. Fasten screws loosely during initial assembly. Do not fully tighten screws until the item is completely assembled.
-
Page 4: Tools Required
TOOLS REQUIRED PHILLIPS DRILL 2PERSON APPROXIMATELY SCREWDRIVER (RECOMMENDED) ASSEMBLY 60MIN. ASSEMBLY HARDWARE M4.0x45 mm SCREW M3.5x60 mm SCREW 28PCS+1 spare 24PCS+1 spare M3.5x50 mm SCREW M3.5x35 mm SCREW 37PCS+1 spare 8PCS+1 spare M3.5x25 mm SCREW M3.0x16 mm SCREW 56PCS+1 spare 30PCS+1 spare Latch Lock... - Page 6 PARTS Right panel of coop Front panel of coop Left panel of coop Back panel of coop Front bottom panel of coop Right bottom panel of coop Left bottom panel of coop Front panel of nesting box Side panel of nesting box 2PCS 2PCS...
- Page 7 PARTS Side panel of nesting box Bottom panel of nesting box Divider of nesting box 2PCS 2PCS 4PCS Round Perch of coop Perch of pen Perch of coop 3PCS 2PCS Tray Roof of nesting box PVC Waterproof Strip 2PCS 2PCS...
- Page 8 PARTS Right roof of coop Left roof of coop Ramp Pen panel Pen panel Pen panel Pen panel Pen panel Pen panel...
- Page 9 PARTS Back pen panel Inner roof of pen Middle roof of pen Outer roof of pen Roof cap Connect bar 2PCS 10PCS Waterproof pvc...
-
Page 10: Product Assembly
PRODUCT ASSEMBLY ① Attach the part A1, part D1 by 2 X P2 screws. ② Attach the part A2, part D2 by 2 X P2 screws. Then attach the part B1, part B2,part C to the step 1 by 16 X P1 screws. - Page 11 PRODUCT ASSEMBLY ① Slide in the tray Part K. ② Insert the perches 3xPart I1 into the slots inside the left and right panel of coop. I1x3 Attach the perch Part J to the slots inside the front and right panel by 1XP3 screws each side.
- Page 12 PRODUCT ASSEMBLY Attach the side panels of nesting box Part F1 & F2 to the coop by 6XP3 screws. Attached the front panel of nesting box Part E to the side by 6XP1 screws.
- Page 13 PRODUCT ASSEMBLY Attach the another side panels of nesting box Part F1 & F2 to the coop by 6XP3 screws. Attached the front panel of nesting box Part E to the side by 6XP1 screws.
- Page 14 PRODUCT ASSEMBLY ① Drop in the bottom panel of nesting box Part G. ② Slide in the divider 2 x Part H each side. Attach the roof of nesting box 2 X Part L to the nesting box by 6XP6 screws each side.
- Page 15 PRODUCT ASSEMBLY Attach the lock 2 X P8 to the nesting box by 6XP6 screws each side. Attach the coop roof Part N1 & Part N2 to the coop by 8XP4 screws.
- Page 16 PRODUCT ASSEMBLY ① Put the Waterproof pvc Part Y in the connection position of 2 roof cap to avoid the water leakage. ② Then attached the roof cap 2 x Part W by 8XP5 screws. ① Attach the pen panel Part P1 to the coop by 3XP2 screws. ② Attach metal rod Part P7 to the back panel of coop by 2xP6 screws.
- Page 17 PRODUCT ASSEMBLY Attach the bottom connecting bars Part X by 4XP5 screws, the position is shown in the picture. ① Attach the pen panel Part P2 to the coop by 3XP2 screws. ② Attach the bottom connecting bars Part X by 4XP5 screws, the position is shown in the picture.
- Page 18 PRODUCT ASSEMBLY Attach the ramp Part O to the coop by 4XP6 screws. Attach the perch Part I2 into the slots inside the inner pen panel Part P1&P2 by 2XP3 screws.
- Page 19 PRODUCT ASSEMBLY Attach pen panel Part Q1 & Q2 by 6XP2 screws. Attach the up and down four connecting bars Part X by 4XP5 screws each, the position is shown in the picture.
- Page 20 PRODUCT ASSEMBLY Attach pen panel Part R1 & R2 to the coop by 6XP2 screws. ① Attach the up and down four connecting bars Part X by 4XP5 each, the position is shown in the picture. ② Attach the perch Part I2 into the slots inside the inner pen panel Part R1 & R2 by 2XP3 screws.
- Page 21 PRODUCT ASSEMBLY Attach the back pen panel Part S to the pen by 6XP3 screws. Attach the pen roof Part T & Part U & Part V by 13XP3 screws.
- Page 22 PRODUCT ASSEMBLY Fix the middle roof panel to the side roof panels by 2XP2 screws. Attached PVC Waterproof Strip Part M to the right side nesting box by 4XP5 screws.
- Page 23 PRODUCT ASSEMBLY Attached PVC Waterproof Strip Part M to the left side nesting box by 4XP5 screws. Finish...
- Page 24 WARNING Manufacturer and seller expressly disclaim any and all liability for personal injury,property damage or loss,whether direct,indirect,or incidental,resulting from the incorrect attachment,improper use,inadequate miantenance,or neglect of this...
