Eclipse Eight Drawer
Assembly Instructions
6
A
9
Attach panels [9] to panel [6] with 2x dowels (A) and secure with 2x
locking nuts (D). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au
D
9
D
D
6
7
D
A
D
7
A
A
D D
3
Attach panel [3] to panels [7], [8] and [9] with 2x dowels (A) and secure
with 4x locking nuts (D). Tighten with a screwdriver.
9
D
8
5
