Mocka Eclipse Assembly Instructions Manual

Eclipse Buffet
Assembly Instructions
Thank you for your purchase. Please follow the instructions for correct assembly.
While we took great effort to ensure these assembly instructions were correct at
the time of printing, sometimes updates are required post production. For the
most up to date versions please refer to the product page on our website.
mocka.com.au/mocka.co.nz
A B C
dowel bolt
screw
x20 x6 x14
I J K
wedge screw
height
x16
adjuster x16
x2
WARNING: Any furniture that is not anchored to a wall has the potential to tip over in certain
circumstances, i.e. if a child attempts to climb up on the furniture or in the event of an earthquake.
Accordingly, we recommend that all furniture is anchored to a wall. We supply a free safety wall anchor
with all furniture sold and we recommend these are used to prevent your product tipping. The fixing device
provided should fit most wall types, but please note that different wall materials may require different fixing
devices from those supplied.
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore, QLD, 4558
E
D F
screw screw
locking
x18 x48
nut x 14
L M N
bolt handle handle
screw
x10
x4
x8
Hardware Supplied
Phillips & Flathead screwdrivers
For quicker assembly, we recommend the
use of a power drill on a low-speed setting.
G H
hinge
screw
x8
x2
O P
buffer Allen
plate Key
x4 x1
V W X
safety screw wall
x2
strap x2 anchor
x2
Wall Strap
Y Z
wall washer
x4
screw
x2
1
