Eclipse Eight Drawer
Assembly Instructions
4
D
A
D
A
D
7
8
Attach panels [7] and [8] to panel [6] with 2x dowels (A) and secure
with 6x locking nuts (D). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au
D
7
A
D D
D
6
5
8
7
5
Slide panels [5] down along the grooves between the panels [7] and
[8] as shown.
7
8
8
5
4
