Mocka Eclipse Eight Drawer Assembly Instructions Manual page 11

Eclipse Eight Drawer
Assembly Instructions
18
Drawers x8
G
G
30
G
G
G
32
30
3 36
x4
Attach panels [30], [31], [32] and [34] together as shown using 40x
screws (G). Tighten with a screwdriver.
mocka.co.nz | mocka.com.au
G
32
G
G
31
3 35
x4
G
G
31
19
Drawers x8
E
E
DR
31
E
36 3
x4
Attach slide rail (DL) and slide rail (DR) to the underside of the side panels [30]
and [31] as shown. Secure with 32x screws (E) and tighten with a screwdriver.
E
DR
31
x4
35 3
30
DL
E
E
30
DL
E
E
11
