Chapter 2 — High Accuracy Power Meter
(Option 19)
2-1

Introduction

This chapter covers the Anritsu High Accuracy Power Meter (Option 19) measurements for in use with
Field Master Series handheld instruments. Instruments with Option 19 and an appropriate Anritsu power
sensor can be used to make high accuracy power measurements. This option provides accurate, true RMS
measurements for both CW and complex digitally modulated signals.
with Anritsu power sensors. This chapter provides a general overview of the instrument and its user interface.
The Anritsu power sensor is not included with Option 19. A high accuracy power sensor must be
Note purchased separately and the instrument must have compatible firmware that supports your installed
sensor. Visit
Table 2-1. Option 19 USB Power Sensors
Model Description
Inline High Power
a
MA24104A
Sensor
Inline Peak Power
b
MA24105A
Sensor
High Accuracy RF
MA24106A
Power Sensor
Microwave USB Power
MA24108A
Sensor
Microwave USB Power
MA24118A
Sensor
Microwave USB Power
MA24126A
Sensor
Universal USB Power
MA24208A
Sensor
Universal USB Power
MA24218A
Sensor
Microwave CW USB
MA24330A
Power Sensor
Microwave CW USB
MA24340A
Power Sensor
Microwave CW USB
MA24350A
Power Sensor
a. The MA24104A sensor is discontinued and is replaced by the MA24105A.
b. The MA24105A provides additional measurement capabilities.
High Accuracy Power Meter MG
www.anritsu.com for details.
Frequency Range
600 MHz to 4 GHz
350 MHz to 4 GHz
50 MHz to 6 GHz
10 MHz to 8 GHz
10 MHz to 18 GHz
10 MHz to 26 GHz
10 MHz to 8 GHz
10 MHz to 18 GHz
10 MHz to 33 GHz
10 MHz to 40 GHz
10 MHz to 50 GHz
PN: 10580-00492 Rev. C
Table 2-1 lists the Option 19 compatible
Data Sheet
Connector (for complete
(50 Ω) specifications)
Type N(f) 11410-00483
Type N(f) 11410-00621
Type N(m) 11410-00424
Type N(m) 11410-00504
Type N(m) 11410-00504
Type K(m) 11410-00504
Type N(m) 11410-00841
Type N(m) 11410-00841
Type K(m) 11410-00906
Type K(m) 11410-00906
Type V(m) 11410-00906
2-1
