1-2 Option Description
1-2 Option Description
This section provides a brief overview of the available options covered in this guide.
Not all instrument models offer every option. Some options are available as a time-limited trial.
For example, High Accuracy Power Meter is offered as a 90-day time-limited option by ordering
Option 9019. The option start time begins when the user first activates the option. Please refer
Note
to the Technical Data Sheet of your instrument for information on purchasing and activating
time-limited options.
The High Accuracy Power Meter Option 19 uses an external USB power sensor (sold separately) to facilitate
high accuracy power measurements using Field Master Series instruments as the host controller. Refer to
Table 2-1, "Option 19 USB Power Sensors
1-3 Document Conventions
The following conventions are used throughout the instrument documentation set.
User Interface Navigation
The instrument user interface consists of menus, buttons, toolbars, and dialog boxes. Elements in navigation
paths are separated as follows: MARKER > PEAK SEARCH > NEXT PEAK.

Illustrations

Screen-captured images contained in this document are provided as examples. The chapters included in this
measurement guide provide information on advanced measurement features, instrument settings and menu
overviews, for a featured option. The actual displays, screen menus, and measurement details may differ based
on the instrument, model, firmware version, installed options, and current instrument settings.
1-4 Calibration and Verification
The instrument comes fully calibrated from the factory and there are no field-adjustable components. Anritsu
recommends annual calibration and performance verification by local Anritsu service centers. Accredited
calibration to ISO17025 and ANSI/NCSL Z540-1 are available and can include a calibration certificate, test
report, and uncertainty data. Contact Anritsu sales and service centers for more information.
1-5 Contacting Anritsu for Sales and Service
To contact Anritsu, visit the following URL and select the services in your region:
http://www.anritsu.com/contact-us
1-2
in Chapter 2.
PN: 10580-00492 Rev. C
General Information
High Accuracy Power Meter MG
