Teknion CWTF Installation Manuals page 20

custom wood
Section: TABLES
Description:
CONFERENCE TABLE
ATTACH RAIL
STEP 19d: Attach frame to the rail.
Installation Guides
NOTE: For Enclosed base only.
J
G
STEP 20d: Fasten and secure the frame with screws as shown.
L
STEP 21d: Fasten frame and bracket on each side with the screws provided as shown.
SECURE RAIL
FASTEN RAIL AND BRACKET
Date: May 2022 Page No: 20 of 21
TCW_101
NOTE: For Enclosed base only.
NOTE: For Enclosed base only.
