Teknion CWTF Installation Manuals page 14

custom wood
Section: TABLES
Description:
CONFERENCE TABLE
ATTACH MID GABLE TO FRAME RAILS
O4
STEP 3b: Attach Mid Gable to the rail and secure with connector bolts as shown.
Installation Guides
NOTE: For Enclosed base only.
ATTACH INNER FRAME RAILS
STEP 4b: Attach rails to the frame from other side.
ATTACH PANEL TO LEGS
O1
STEP 5b: Attach panel to the outer legs as shown and secure with connector bolts.
Date: May 2022 Page No: 14 of 21
TCW_101
NOTE: For Enclosed base only.
