Home Decorators Collection Chartwell Owner's Manual page 9

Extension cord
Cross pin
Set screw
Canopy Bottom
Cover
Pin in locked
position
Motor
collar
Clevis pin
Installing Fan to the
Electrical Box
Ground lead WARNING
TO REDUCE THE RISK OF FIRE, ELECTRIC
Hanger ball SHOCK OR OTHER PERSONAL INJURY. MOUNT
FAN ONLY TO AN OUTLET BOX OR SUPPORTING
Downrod
SYSTEM MARKED ACCEPTABLE FOR FAN
Ceiling canopy SUPPORT AND USE THE MOUNTING SCREWS
PROVIDED WITH THE OUTLET BOX.
Motor wires Pass the 120-volt supply wires through the
1.
center hole in the ceiling mounting bracket as
shown in Figure 9.
Coupling cover
Attach the mounting bracket on the outlet box
2.
by sliding the mounting bracket over the screws
provided with the outlet box. (Figure 9)
Cotter pin Cotter pin
Securely tighten the two mounting screws.
3.
Tighten
(Figure 9)
screws
firmly
Carefully lift the fan assembly up to the
4.
ceiling mounting bracket and seat the hanger
ball in the mounting bracket socket. Make
sure the tab on the mounting bracket socket is
properly seated in the groove in the hanger
ball (Figure 10). This will help to balance the
Figure 8
ceiling fan.
NOM listed
outlet box
Mounting
screws (Supplied
with outlet box)
Ceiling mounting
bracket
Tab
WARNING
THE TAB IN THE RING MUST REST IN THE
GROOVE OF THE HANGER BALL AS FIGURE 10.
FAILURE TO PROPERLY SEAT THE TAB IN THE
GROOVE COULD CAUSE DAMAGE TO WIRING.
120V
Wires
Figure 9
Groove
Figure 10
5
