7.
Make wire connections from the fan to the
receiver. (Figure 13)
From Fan To Receiver
3-Pin Connector ............. 3-Pin Connector
8.
Make wire connections from the receiver and
fan to the outlet box as follows, using the wire
nuts. (Figure 13)
From Receiver To Outlet Box
Black Wire "AC in L" ..... Black Wire (Hot)
White Wire "AC in N" .....White Wire (Neutral)
From Fan and Receiver To Outlet Box
Green Wires*................. Green or Bare Wire
(Ground)
* There are two green grounding leads: one from
the mounting bracket and one from the hanger
ball/downrod assembly.
9.
Turn the wire nut connections upward, spreading
them apart so the green (ground) and white
wires will be on one side of the outlet box and
the black and blue wires will be on the other
side. Carefully tuck the connections up into the
outlet box.
NOTE
FAN MUST BE INSTALLED AT A MAXIMUM
DISTANCE OF 20 FEET FROM THE TRANSMITTING
UNIT FOR PROPER SIGNAL TRANSMISSION
BETWEEN THE TRANSMITTING UNIT AND THE
FAN'S RECEIVING UNIT.
WARNING
CHECK TO SEE THAT ALL CONNECTIONS ARE
TIGHT, INCLUDING GROUND, AND THAT NO BARE
WIRE IS VISIBLE AT THE WIRE NUTS. EXCEPT FOR
THE GROUND WIRE.
NOTE
DO NOT CUT THE YELLOW ANTENNA WIRE.
SUPPLY CIRCUIT
Ground
Black White Conductor
Outlet Box
Antenna
DIP
1 2 3 4
Figure 13
