Unpacking Your Fan

1
1. Set of blades (5)
2. Canopy assembly
3 Ball/downrod assembly
4. Coupling cover
5. Fan motor assembly
6. Blade arms (5)
WARNING
DO NOT INSTALL OR USE FAN IF ANY
PART IS DAMAGED OR MISSING.
CALL TOLL FREE 800-004-6633.
2
Unpack your fan and check the contents. You should have the following items:
2
3
4
7. 20 watt LED Light kit
8. Glass shade
9. Receiver
10. Remote control
11. 23A 12V battery
5
8
6
9
7
11
10
This fan includes a 20W LED light. The purchaser should return the fan to the original
store of purchase during the warranty period in case of the light not working.
A B
C D
A. Blade Attachment Hardware Blade Attachment Hardware
(16 Screws, 16 Fiber Washers)
(7 Screws, 7 Lock Washers)
B.
Blade Attachment Hardware
Electrical Hardware
(11 Screws with Lock Washers)
(3 Plastic Wire Nuts)
C. Electrical Hardware
(3 Plastic Wire Nuts)
D.
Extension cord
