Introduction
Display:
Supports simultaneous display for CRT & Panel.
Supports 32-bit PCI Local Bus.
VGA BIOS combines 128/256KB flash ROM with system BIOS.
Supports 15 pin connector 1024 x 768 resolution (256 colors) on
SVGA Monitor.
Supports 2 MB video memory (4 MB optional).
Supports 51-pin connector 640 x 480, 800 x 600 resolution on
LCD Panel.
Panel support Color STN and TFT modes.

Watchdog Timer:

The watchdog timer is controlled by software. Once enabled, the
system will reboot, unless the timer is re-enabled before the
specified timeout duration expires. Timeout durations range from
zero to 120 seconds in eight-second increments (+/- 25%).

IDE Interface:

Two Enhanced IDE ports. Supports up to four Enhanced IDE
devices.
Supports Ultra DMA-33.
Floppy Disk Driver Interface:
Supports up to two floppy disk drives: 3.5" and 5.25" (360K /
720K / 1.2M / 1.44M / 2.88M / LS-120).
Disk-on-Chips Socket:
32-pin SSD socket on board, supports up to 144MB disk-on-chip.

USB Connector:

Universal Serial Bus Connector on board, supports up to two
USB ports.

LAN Adapter:

Realtek RTL8139 Fast Ethernet.
10/100 Base-T PCI-Bus.
Wake on LAN support.
8 CommPlete 4000 Server SBC, Model IPC-623C
