Hardware Configuration
Jumper Diagrams
Jumper Settings
1
1
1 2
14
Jumper cap looks like this
2 pin jumper looks like this
3 pin jumper looks like this
Jumper block looks like this
2 pin jumper closed (enabled)
looks like this
3 pin jumper
2-3 pin closed (enabled)
looks like this
Jumper Block
1-2 pin closed (enabled)
looks like this
CommPlete 4000 Server SBC, Model IPC-623C
1
1
1 2
