Hardware Configuration
2-25 LCD VDD Selection
JP4: LCD VDD Selection
The selections are as follows:
Power
Selection
VDD 5V
VDD 3.3V
2-26 Panel Power Connector
JP5: Panel Power Connector
JP5 : Panel Power Connector
The pin assignments are as follows:
PIN
1
2
3
32
Jumper Settings
(Pin Closed)
1-2
2-3
SIGNAL FUNCTION
LCD+12V
GND
LCD VDD (+5V/3.3V)
CommPlete 4000 Server SBC, Model IPC-623C
Jumper
Illustration
3
JP4
3
JP4
