Video Off Method

This category determines the manner in which the monitor is
blanked.
V/H SYNC+BLANK This selection will cause the system to turn off the
BLANK SCREEN
DPMS
Video off After
When enabled, this feature allows the VGA adapter to operate
in a power saving mode.

Modem Use IRQ

This item enables you to name the interrupt request (IRQ) line
assigned to the modem (if any) on your system. Activity of the
selected IRQ always awakens the system.

Doze Mode

When enabled and after the set time of system inactivity, the
CUP clock will run at slower speed while all other devices still
operate at full speed.

Standby Mode

When enabled and after the set time of system inactivity, the
fixed disk drive and video will shut down while the other devices
still operate at full speed.

Suspend Mode

When enabled and after the set time of system inactivity, all
devices except the CPU shut down.

HDD Power Down

When enabled and after the set time of system inactivity, the
hard disk drive will power down while all other devices remain
active.
CommPlete Series 4000 Server SBC, Model IPC-623C
vertical & horizontal synchronization ports and
write blanks to video buffer.
This selection only writes blanks to video buffer.
Initial display power management signaling.
