TYPE button. Click the CHANGE button in the "Adapter
Type" area.
(4). Push the "HAVE DISK BUTTON" and press OK.
(5). Specify the path for the new driver and press the <Enter>
key. The "Select Device" dialog box will appear. Select the
"Chips and Tech 69000 PCI".
(6). Follow the remaining instruction that appear on the screen
to complete the rest of the installation, then restart your
computer.
3. Install VGA driver to Windows NT 3.5x/4.0
(1). To install VGA drivers to Windows 3.5x/4.0 is as you
normally would. Click START, then SETTINGS, then
CONTROL PANEL of the operating system.
(2). Select the DISPLAY icon to start the DISPLAY
PROPERTIES window, then choose the SETTING tab, then
DISPLAY TYPE.
(3). In the CHANGE DISPLAY TYPE window, click on the
CHANGE button in the ADAPTER TYPE, this will bring up
the SELECT DEVICE window.
(4). In the CHANGE DISPLAY window, click on Have Disk.
Follow the instructions appearing on the screen until you
complete the whole installation.
(5). Once installation is completed, the system must be shut
down and restarted for the new drivers to take effect.
4. Install VGA driver to OS/2 Warp Operation System
(1) Preliminary Steps:
(i) OS/2 DOS Support must be installed.
(ii) If you previously installed SVGA support, you must reset
the system to VGA mode. VGA is the default video mode
enable when OS/2 is to be installed.
(iii) To restore VGA mode, Use SELECTIVE INSTALL and
select VGA for PRIMARY DISPLAY. For more
information on this procedure, see the section on
Changing Display Adapter Support in the OS/2 User's
Guide.
CommPlete 4000 Server SBC, Model IPC-623C
Software Configuration
