Features

• STM32C031C6 microcontroller based on the Arm
and 12-Kbyte SRAM, in an LQFP48 package
• User LED shared with ARDUINO
• User and reset push-buttons
• 32.768 kHz crystal oscillator
• Board connectors:
– ARDUINO
– ST morpho extension pin headers for full access to all STM32C0 I/Os
• Flexible power-supply options: ST-LINK USB V
• On-board ST-LINK/V2-1 debugger/programmer with USB re-enumeration capability: mass storage, Virtual
COM port, and debug port
• Comprehensive free software libraries and examples available with the
• Support of a wide choice of Integrated Development Environments (IDEs) including IAR Embedded
Workbench
Note: Arm is a registered trademark of Arm Limited (or its subsidiaries) in the US and/or elsewhere.
UM2953 - Rev 1
®
®
Uno V3 expansion connector
®
, MDK-ARM, and STM32CubeIDE
® ®
Cortex -M0+ processor with 32-Kbyte Flash memory
or external sources
BUS
STM32CubeC0
UM2953
Features
MCU Package
