6.2

Default board configuration

Jumper
CN2 SWD interface
JP5 5 V power selection
JP1 STLK reset
JP6 IDD measurement
6.3

Cuttable PCB

The STM32 Nucleo-64 board is divided into two parts: the ST-LINK part and the target MCU part. The ST-LINK
PCB part is cuttable to reduce the board size. In this case, the remaining target MCU part is only powered by VIN,
E5V, and 3.3V on CN7 morpho connectors, or VIN and 3.3V on CN6 ARDUINO
to use the ST-LINK part to program the main MCU using wires between CN7 and SWD signals available on the
ST morpho connectors.
6.4

Embedded ST-LINK/V2-1

The ST-LINK/V2-1 programming and debugging tool is integrated into the NUCLEO-C031C6 Nucleo-64 board.
The additional features supported on the ST-LINK/V2-1 are:
• USB software re-enumeration
• Virtual COM port interface on USB
• Mass storage interface on USB
• Registers read/write interface on USB (Not available on Nucleo)
• USB power management request for more than 100 mA power on USB
The following features are no more supported on the ST-LINK/V2-1:
• SWIM interface
• Minimum application voltage supported by Nucleo limited to 3 V
• Standalone version does not exist. Only Nucleo and future discovery support V2-1.
For information about debugging and programming features, refer to the user manual ST-LINK/V2 in-circuit
debugger/programmer for STM8 and STM32 (UM1075), which describes in detail all the ST-LINK/V2 and ST-
LINK/V2-1 common features.
The embedded ST-LINK/V2-1 is usable in two different ways according to the jumper states (Refer to
• Program/debug the on‑board STM32,
• Or program/debug an STM32 in an external application board using a cable connected to the SWD
connector.
Jumper
CN2 T_SWCLK / T_SWDIO
6.4.1

Drivers

ST-LINK/V2-1 requires a dedicated USB driver, which, for Windows 7
available from www.st.com.
UM2953 - Rev 1
Table 4. Default jumper settings
Definition Default position
Table 5. ST-LINK jumper configuration
Definition Default position
[1-2]
On-board ST-LINK/V2-1 debugger
[3-4]
[1-2] 5 V from ST-LINK
OFF No STLK reset
ON STM32 VDD current measurement
®
connector. And it is still possible
[1-2]
ST-LINK/V2-1 functions enabled for on-board
programming (Default setting)
[3-4]
OFF
ST-LINK/V2-1 functions enabled from external
connector (SWD supported)
OFF
® ®
, Windows 8
UM2953
Default board configuration
Comment
Table 5):
Comment
®
and Windows 10 , is
page 11/32
