Pre-installation and application warnings

This section highlights important information for this specific firmware and will assist in pricing accordingly, as
START HERE
well as bringing awareness to any operational or vehicle limitations.
Compatibilities and Requirements
T-Harness
compatible
Vehicle Takeover
Firmware notes
Manual transmission: Not compatible with vehicles equipped with a manual transmission.
Š
Factory hood pin: In vehicles not equipped with a Factory Hood Pin, must permanently ground the vehicles N.C. OEM Hood Pin
Š
input for successful operation. See Directechs for hood pin location.
Note: Does not apply to vehicles with a (-) Hood pin such as the 2017+ F-250 - F-450.
Pit Stop: The vehicle pit stop/idle mode feature is not available in this firmware.
Š
The optional Plug & Play THFON2 T-Harness is sold separately
Š
Loose wires: All T-Harness wires not listed in the diagram are not required for the installation. Loose wires such as Siren Output and
Š
Hood Input may need to be pulled from the tapped section of the T-harness. Refer to the "wiring diagram with T-Harness" for more
information on connections and installation instructions.
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Š
All connectors are displayed from the wire side (unless specified otherwise).
Š
Fuses positioning: It is important to check that the fuses are positioned correctly in the module. Proper fuse positioning is displayed
Š
on each wiring diagram.
Refer to the "Vehicle connections" following the installation diagram.
Š
Conditions and Limitations
Š This installation enables the OEM remote starter and the remote start system will not work in the following conditions:
Š The ignition is on.
Š The alarm system is triggered.
Š The doors/hood are open.
Š The transmission is not in Park (P).
Š The vehicle battery voltage is too low.
Š The service engine light is on.
Note: Any stored DTC code errors will prevent vehicle from remote starting (no visual lights on dash).
RS Features: The following remote starter features can be configured via the information display:
Š
Š Climate control
Š Heated seats/steering wheel
Š Runtime (for best results, program the remote starter runtime to match the OEM setting)
Š Remote Starter enable/disable
Footnotes
[1] Hood pin: The installation of an aftermarket hood pin is only required on vehicles that are not equipped with a factory hood pin or if
not supported in data.
[2] Siren: The siren is only required when enabling the security features during module flashing.
[3] Security-Only installations: For vehicles only equipped with a Key, refer to "Starter disable connection". Not compatible with Smart
Key vehicles.
5
933.FORD12 1.60.195.3 2017 Ford Edge (Smart Key)
©2022 VOXX•DEI LLC. All rights reserved.
THFON2
Refer to the Quick Reference Guide section for more details.
Keys required for 1 Keys required
programming for operation
0
