Summary of Contents for AudioCodes 400HD Series
Page 1
User's and Administrator's Manual AudioCodes 400HD IP Phone Series C448HD | C450HD IP Phones Microsoft Teams Application Version 1.17 ...
Page 2
Customer Support Customer technical support and services are provided by AudioCodes or by an authorized AudioCodes Service Partner. For more information on how to buy technical support for ...
Page 3
Notice C448HD C450HD | Users & Administrator's Manual Document Name Device Manager Deployment Guide https://docs.microsoft.com/en-us/MicrosoftTeams/phones-for-teams - iii -...
Running Android in Kiosk Mode Screen Lock AudioCodes Private Key Android Debug Bridge (ADB) App Signing Web Browser Remote Configuration Management AudioCodes Device Manager Validation Sandboxing Device File System Keystore Device Certificate Data Protection Debugging Interface SSH Access: Reduced File System Privileges...
Page 5
Content C448HD C450HD | Users & Administrator's Manual Recovery Mode Locking and Unlocking the Phone Automatic Lock Unlock Teams Application Signing In Multi-Cloud Sign-in Remote Provisioning and Sign-in from Teams Admin Center Getting Acquainted with the Phone Screen Enabling Google Talkback Opting in or out of Call Queues Setting Status Hot Desking...
Page 6
Performing Administrator-Related Operations Setting up an E911 Emergency Location using TAC Updating Phone Firmware Manually Downloading Certificates AudioCodes Android Phone Utility Manually Performing Recovery Operations Removing Devices from Intune Management Configuring Audio-Related Parameters for Noisy Environments Updating Microsoft Teams Devices Remotely...
Page 7
Content C448HD C450HD | Users & Administrator's Manual Capturing Traffic Using 'rpcapd' Port Mirroring Network Monitoring - vii -...
AudioCodes' Device Manager and AudioCodes' Redirect Server are also supported for monitoring, upgrading and configuring the devices. The phones feature the option to be used as a Microsoft Teams Compatible IP phone, offered as part of AudioCodes’ Managed IP Phones solution which defines the IP phone as an IT- managed entity and delivers unique and complete lifecycle management of end-user desktop devices. ...
Page 9
Calendar and Presence (roadmap feature) (Calendar Access and ■ Meeting Details; Presence Integration; Exchange Calendar Integration; Contact Picture Integration; Corporate Directory Access) ■ Meetings (roadmap feature) (One-click Join for Meetings; Join Skype for Business meetings; Meeting Call controls [Mute/unmute, hold/resume, hang up, add/remove participant]; Meeting Details. See also here for related Microsoft documentation. Configuration Teams admin center (TAC) ■ and ■ OVOC / Device Manager Management Debugging AudioCodes' Android Phone Utility (see Android Phone Utility on ■ Tools page 105) Log upload to Microsoft server (certification for 3rd party Skype for ■ Business clients) ■ Remote logging via Syslog SSH Access ■ ■ Capturing the phone screen TCPdump ■ ■ Audio Debug recording logs Media logs (*.blog) ■ ■...
Page 10
CHAPTER 1 Overview C448HD C450HD | Users & Administrator's Manual Feature Details ■ Remote Packet Capture network sniffer application Localization Multi-lingual support; the language pack list is not yet final and is ■ Support subject to modification. Hardware ■ Five-inch color capacitive touch screen, 1280 x 720 resolution, with an intuitive user interface. Wired connectivity: ■ ✔ Two RJ-45 [Gigabit Ethernet (GbE)] (10/100/1000BaseT Ethernet) ports: LAN and PC port ✔ RJ-9 port (jack) for headset [C450HD] USB port for USB headset ✔ C450HD with DBW suffix flavor: ● White USB port - host port for USB headset ● Black USB port - default port but can be configured to host port. To configure device / host port: setup_usbport2_mode.sh host (from device to host) ...
Allowing URLs, Ports (Security) This section shows network administrators which URLs/Ports to allow when deploying Teams phones (security). From the device point of view, the following table summaries the ports the phone uses. See also Microsoft's guide to the ports the phone uses. Table 1-2: URLs / Ports to Allow when Deploying Teams Phones (Security) Server Role Service Name Port Protocol Notes DNS Server All 53 AudioCodes AudioCodes 443 HTTPS AudioCodes device Device management server Manager - 4 -...
CHAPTER 1 Overview C448HD C450HD | Users & Administrator's Manual Server Role Service Name Port Protocol Notes AudioCodes AudioCodes 443 HTTPS AudioCodes redirect service Redirect redirect.audiocodes.com service NTP Android NTP 123 timeserver Time Zone Time Zones 443 HTTPS Time Zone Database ( often Database called tz or zoneinfo) Microsoft Package ...
CHAPTER 1 Overview C448HD C450HD | Users & Administrator's Manual Sign in to Microsoft Teams - Microsoft Teams | Microsoft Docs ■ Android-Level Security Hardening Major Android- level system- level developments have been incorporated into AudioCodes' devices to improve security: ■ See Google Play Services below ■ See Running Android in Kiosk Mode below See Screen Lock on the next page ■...
AudioCodes Private Key The system software on AudioCodes devices is signed with AudioCodes' private key. Users can replace the complete software only with new software that is also signed by AudioCodes' private key. This prevents users from replacing the complete over-the-air (OTA) package of the device with any new system software, unless the software is fully signed by AudioCodes. Android Debug Bridge (ADB) The device does not allow access to ADB.
Device Manager, the user can replace the Root CA on the Device Manager and on the phone, and re-establish the connection leveraging any Private Root CA. Sandboxing AudioCodes devices use Android Application Sandbox so that each application can access its own data and is isolated from other applications. This prevents a malicious app from accessing the code or the data of other applications in the system. Device File System The AudioCodes device's file system is encrypted on C450HD-DBW devices. Customers may enforce a policy of device encryption via Microsoft's cloud-based Intune service. Keystore With AudioCodes devices, the certificate keys are encrypted on the device file system. Device Certificate AudioCodes devices are shipped with a unique certificate which is signed by AudioCodes Root CA. Network administrators can install a third-party certificate on the phone in the customer’s trusted environment. Network administrators should follow the following guidelines when ...
CHAPTER 1 Overview C448HD C450HD | Users & Administrator's Manual Use the following two parameters to set the device certificate in the phone's configuration ■ file: ● security/device_certificate_url=http://<server-ip>/device.crt ● security/device_private_key_url=http://<server-ip>/device.key Data Protection AudioCodes devices run Android which has integral procedures for protecting and securing user data. Debugging Interface ■ AudioCodes devices leverage SSH as a debugging interface. AudioCodes recommends that customers disable SSH on devices via AudioCodes' Device ■ Manager (OVOC). ■ AudioCodes recommends changing the Admin password from the default, via the Teams Admin Center or AudioCodes' Device Manager (OVOC). ■ When a device - or multiple devices - needs to be debugged, users can enable SSH on it / them, access SSH with the new Admin password for the debugging phase, and disable SSH once debugging is finished. SSH is by default disabled and can be enabled with Administrator permissions in the phone screen (Device Administration >...
1.14 and then to 1.17. ✔ Customers with 1.8 / 1.10 cannot use the TAC to upgrade to 1.17. An upgrade can be performed using AudioCodes Device Manager or AudioCodes Android Phone Utility. Contact AudioCodes support for further assistance.
The instructions following show how to set up the phone. Unpacking When unpacking, make sure the items listed in the phone's Quick Guide are present and undamaged. If anything appears to be missing or broken, contact the distributor from whom you purchased the phone for assistance. For detailed information, see the phone's Quick Guide shipped with the device or available from AudioCodes. - 13 -...
CHAPTER 2 Setting up the Phone C448HD C450HD | Users & Administrator's Manual Device Description Use the following graphics to identify and familiarize yourself with the device's hardware functions.
Page 22
CHAPTER 2 Setting up the Phone C448HD C450HD | Users & Administrator's Manual Item # Label/Name Description ■ Red: Answered call TFT touch screen Thin Film Transistor touch screen, a type of LCD (Liquid Crystal Display) interactive screen which displays information and lets you configure features by touch. Navigation Control ■ Press the button's upper rim to scroll up menus/items. / OK Press the lower rim to scroll down. ■ ■ Press the left or right rim to move the cursor left|right (e.g., when editing a contact number). ■ Press OK to select a menu/item/option. Voicemail Retrieves voicemail messages. CONTACTS Accesses the People screen. MENU Accesses the Settings screen. REDIAL Accesses a list of recently dialed numbers; one can be ...
CHAPTER 2 Setting up the Phone C448HD C450HD | Users & Administrator's Manual Rear View The ports located on the rear of the phone are described in the table. Figure 2-2: Rear View Table 2-2: Rear View Description Label Description Handset jack, i.e., port RJ-9, to connect the handset. RJ-45 port to connect to the Ethernet LAN cable for the LAN connection (uplink - 10/100/1000 Mbps). If you're using Power over Ethernet (PoE), power to the phone is supplied from the Ethernet cable (draws power from either a spare line or a signal line). RJ-45 port to connect the phone to a PC (10/100/1000 Mbps downlink). 12V DC power jack that connects to the AC power adapter. Headset jack, i.e., RJ-9 port that connects to an external headset. - 16 -...
See the phone's Quick Guide shipped with the device and also available from AudioCodes for detailed information on how to cable the phone. Mounting the Phone The phone can be mounted on a: ■ Desk (see Desktop Mounting below) Wall (see Wall Mounting below) ■ See the phone's Quick Guide shipped with the device and also available from AudioCodes for detailed information on how to mount the phone. See also here f or a clip showing the principle of how to mount an AudioCodes IP phone. The principle is the same across all AudioCodes IP phones. Desktop Mounting The following instructions show how to mount the phone on a flat surface like a desk. ➢ To mount the phone on a flat surface like a desk: Off-hook the handset (if on-hook) and place the phone upside down, i.e., base-up, on your desktop. On the phone's stand, identify outer notches. On the phone's base, identify outer rails. Invert the stand and align its outer notches with the base's outer rails. Insert the stand's outer notches into the base's outer rails and slide the notches along the ...
CHAPTER 2 Setting up the Phone C448HD C450HD | Users & Administrator's Manual If the phone model you have has an Expansion Module attached, wall mounting isn't supported. ➢ To mount the phone on a wall: Attach the stand of the phone for the purpose of a wall mounting: Detach the base. Attach it again as you did for a desktop mounting (see Desktop Mounting on the previous page) only now make sure that it's flatly aligned to lie flush against the wall, i.e., slide the inner rails of the phone stand onto the phone base's inner notches. Connect the AC power adapter, LAN and PC/laptop cords.
CHAPTER 2 Setting up the Phone C448HD C450HD | Users & Administrator's Manual Before Using AudioCodes Devices AudioCodes recommends frequently cleaning devices' screens especially screens on devices in common use areas such as conference rooms and lobbies. ➢ To clean a device's screen: Disconnect all cables. Spray onto a clean, dry, microfiber duster a medicinal isopropyl alcohol and water solution of 70:30. Don't oversaturate the duster. If it's wet, squeeze it out. Lightly wipe the screen of the device. Wait for the screen to dry before reconnecting cables. - 19 -...
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Starting up Here's how to start up the phone. ➢ To start up: Connect the phone to the network (or reset it); the language selection screen is displayed by default. Select the language of your choice and then configure device settings to suit specific requirements. It will be necessary to repeat this only if the phone is restored to default settings. Configuring Device Settings The ...
Page 28
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual View the settings under 'User'. Select a setting to open it. Use the table following as reference. [To view settings related to the network administrator, scroll down and open 'Device administration']. Table 3-1: Device Settings Setting Description User Display Opens the ‘Display’ screen [Brightness level]. The phone's screen supports different brightness levels. Choose the level that suits your requirements. ■ Sleep ■ Screen saver - 21 -...
Page 29
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description ■ Font size Sound Allows you to customize phone volume for a friendlier user experience. Ring volume at n% Date & time Date and time are automatically retrieved from the deployed Network Time Protocol (NTP) server. - 22 -...
Page 30
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description Use 24-hour format [Allows you to select the Time format] Also supported is a simplified version of NTP called Simple Network Time Protocol (SNTP). Both can be used to synchronize device clocks. SNTP is typically used if full implementation of NTP is not required. Wi-Fi The phone can connect to an Access Point via Wi-Fi. See the phone's Quick Guide for detailed information on setting up Wi-Fi. See also Configuring Wi-Fi on page 34 in this document for information about configuring the feature. Accessibility Allows making the screen reader-friendlier. See also Enabling Google Talkback on page 50. Bluetooth [Applies only to C450HD] Hands free profile where the phone is able to connect to Bluetooth headset or speaker. See the phone's Quick Guide for detailed information on setting up Bluetooth. Power Saving Allows users to contribute to power saving in the enterprise. - 23 -...
Page 31
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description Enable power saving Start time [The device consumes minimal energy before the user arrives at the office] End time [The device consumes minimal energy after the user leaves the office] Debugging Enables users to reboot the device. Log in as Administrator for more debugging settings to be available. Security Helps secure the enterprise telephony network against breaches. Screen lock [The phone automatically locks after a configured period to secure it against unwanted use. If left unattended for 10 minutes - 24 -...
Page 32
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description (default), it automatically locks and is inaccessible to anyone who doesn't know its lock code.] Make passwords available Touch screen Allows users to disable the phone’s touch screen. Languages Allows users to customize inputting to suit personal requirements. & input About Enables users to determine device information. [Android 7.1.2] To determine the device’s IP address, select the ‘Status’ option. To get information about the version, select ‘Version info’. - 25 -...
Page 33
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description To get information about the Android version, select ‘Android version’. Device administration Device Allows the user to log in as Administrator, necessary for some of the administration debugging options. It is password protected. Default password: 1234 (or 1111 in early versions). After logging in as an Administrator, the user can log out | change password. Select Login and then in the Login screen that opens, select the 'Enter password' field and use the virtual keyboard to enter the password (1234 or 1111). Note that the virtual keyboard pops up for all ‘Settings’ fields to allow inputting characters and / or numbers. Two virtual keyboard types can be displayed: Numeric o r QWERTY. - 26 -...
Page 34
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description The virtual keyboard is also displayed when the network administrator needs to enter an IP address to debug, or when they need to enter their PIN lock for the security tab. After logging in, scroll down in the Settings screen to the section 'Device administration'. Modify network Enables the Admin user to determine network information and to modify network settings. - 27 -...
Page 35
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description IP Address [Read Only] IP Settings [DHCP or Static IP] Network state [Read Only] Enable PC port Enable PC port mirror Proxy 802.1x Settings VLAN Settings. Allows you to configure the VLAN mode Manual, CDP only or LLDP only. Proxy The phone can be configured with an HTTP Proxy server by an Admin user in two ways: ■ Manually. T he Admin user can use this method to configure HTTP proxy server parameters through the Teams application: Log in as Administrator and select Modify network. Select the Proxy option and then configure the proxy host name and port: - 28 -...
Page 36
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description Over DHCP with Option 252. It's recommended that the Admin ■ user uses this method when provisioning multiple phones. Option 252 provides a DHCP client with a URL to use to configure its proxy settings: The proxy setting is provided in a Proxy Auto-Configuration (PAC) file that contains a set of rules coded in JavaScript which allows a web browser to determine whether to send web traffic directly to the Internet or to be sent via a proxy server. PAC files control how the phone handles HTTP, HTTPS and FTP traffic. Example of a basic PAC file: function FindProxyForURL(url, host) return "PROXY 10.13.2.40:3128"; - 29 -...
Page 37
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description If the enterprise features a proxy server that requires user authentication, the network administrator can use the PAC file and DHCP Option 252 to configure it. Alternatively, the administrator can configure it using the following parameters: http_client/fwd_proxy/ip=0.0.0.0 http_client/fwd_proxy/password= http_client/fwd_proxy/port=8080 http_client/fwd_proxy/username= 802.1x Settings 802.1X Authentication is the IEEE Standard for Port-based Network Access Control (PNAC). See https://1.ieee802.org/security/802-1x/ for more information. To configure an 802.1X Authentication method: From the ‘Modify Network’ screen (as an Admin), access the 802.1x Settings screen. From the 'EAP method' drop-down, select the method: MD5 or TLS (for example). Enter this information: Identity: User ID ✔ ✔ Password ✔ root certificate (not required for every method) ✔...
Page 38
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description 802.1x. The 802.1x settings available in the Configuration File are: Enable/Disable ■ ■ EAP method Identity ■ ■ Password VLAN Settings Select the menu option VLAN Settings. Select VLAN Discovery mode. Cisco Discovery Protocol (CDP) is a Cisco proprietary Data Link ■ Layer protocol Link Layer Discovery Protocol (LLDP) is a standard, layer two ■ discovery protocol Select the mode you require and then select OK. If you select Manual configuration, this screen opens: - 31 -...
Page 39
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description Select VLAN Interval. The 'VLAN interval' refers to CDP/LLDP advertisements' periodic interval. D efault: 30 seconds. You can increase or decrease the intervals between the CDP/LLDP packets that are sent, based on network traffic and topology. Region Select the menu option Region preference. preference This option allows you to define the country in which the phone is located. The setting determines which regional tone the phone will use. Call Progress Tones (CPTs) are country-specific; the behavior and parameters of analog telephones lines vary from country to country. - 32 -...
Page 40
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description Select Regional Tone Settings and select the country in which the phone is located. Debugging Allows the Admin user to perform debugging for troubleshooting purposes. Available after logging in as Admin. Log settings Remote Logging (see under Remote Logging (Syslog) on page 110 for more information) Diagnostic Data (see under Getting Diagnostics on page 111 for more information) Reset configuration Restart Teams app Company portal login Debug Recording (for Media/DSP debugging) (see under Remote Logging (Syslog) on page 110 for more information) - 33 -...
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Setting Description Switch to Teams Compatible (not applicable to the C448HD phone) Factory data reset (the equivalent of restore to defaults; including logout and device reboot) ADB (Android Debug Bridge command-line tool used to debug the Teamsapp); the setting is disabled by default. The device does not allow access to ADB. Screen Capture. By default, this setting is enabled. If it's disabled, the phone won't allow its screens to be captured. Configuring Wi-Fi [Applies to devices whose PN indicates DBW ] Network administrators can configure Wi- Fi parameters for the phone. The parameters are concealed from the user's view. ...
Page 42
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual The following table shows the parameters per index. The phone can currently store 16 connected SSIDs. Table 3-3: Wi-Fi Parameters per Index Parameter Description Values network/wifi/[0- Saves the Access Point’s SSID. 15]/ssid network/wifi/[0- Saves the password for some authentication 15]/password methods which need it, e.g., WPAPERSONAL,WPA2PERSONAL network/wifi/[0- Saves the Access Point’s authentication method: 15]/security WPAPERSONAL, WPA2PERSONAL, WPAENTERPRISE, WPA2ENTERPRISE network/wifi/[0- Configure this parameter to reconnect this SSID 1 (default, 15]/auto_reconnect automatically. enable) ...
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Restoring the Phone to Default Settings Users can restore the device to factory default settings at any time. The feature can be used if a user forgets their Admin password, for example. Two kinds of restore are available: ■ Performing a Hard Restore below Performing a Soft Restore below ■ Performing a Hard Restore You can either: perform a hard restore while the phone is up and running (see below) ■ ■ restore the phone’s settings to their defaults when the phone is not connected (see below) ➢ To perform a hard restore while the phone is up and running: Long-press the HOLD key on the phone (more than 15 seconds); the screen shown below is ...
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual Select the Factory data reset option; the device performs a restore to default factory settings. Recovery Mode If a phone goes into recovery mode, you can boot it using its hard keys as shown in Performing a Hard Restore on the previous page. Locking and Unlocking the Phone As a security precaution, the phone can be locked and unlocked. The feature includes: ■ Unlock (see Unlock below) Automatic lock (Automatic Lock below) ■ Automatic Lock Users can lock their phones as a security precaution. Configure the phone with any of the lock options before attempting to lock it. If an option isn't configured, the action won't function. ➢ To lock the phone: ■ Press the back key on the phone for at least three seconds for the device to automatically lock. ...
Page 45
CHAPTER 3 Starting up C448HD C450HD | Users & Administrator's Manual View the digits displayed as you type: When the phone detects the unlock code, it unlocks. - 38 -...
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Teams Application The following describes functions related to the phone’s Microsoft Teams application. Signing In Using TeamsIPPhonePolicy, network administrators can create the following users who can then sign in to the phone: ● UserSignin: All features are available, i.e., calls, meetings and voicemail ●...
Page 47
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual the actual geographical location, therefore the displayed time might be incorrect in some cases. For example, if the given time offset is GMT-5 and the phone is located in Mexico, the phone will get the time (and the DST setting) from central time and not from Mexico because in GMT-5 there is also Central Daylight Time. If the internet connectivity check fails, a ‘No Internet Access’ warning pops up on the phone screen. Figure 4-1: Internet Connectivity Check - No Internet Access This can point to a problem that is preventing the phone from fully functioning in a Teams environment. The user can ignore the message if the Teams application is fully functioning, or can report a problem if the Teams application is not fully functioning. ➢ To sign in: Connect the device to the network; this screen is then displayed: Open your browser and point it to https://microsoft.com/devicelogin as instructed in the preceding screen. - 40 -...
Page 48
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Enter the code and then click Next. Click the account. Enter your password (it's the same password as the Windows password on your PC) and then click Sign in. - 41 -...
Page 49
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Close the window shown in the preceding figure. Observe that the phone returns to the initial code screen. In that screen, select Sign in on this device. Select the 'Email, phone or username' field; a virtual keyboard pops up. Enter one of them and then choose Sign in. The 'home' screen opens. ● If you opt to Sign in from another device, complete authentication from your PC or smart phone. This is recommended if you’re using Multi Factor Authentication (MFA). Figure 4-2: Sign-in from PC / Smart Phone In the browser on your PC or smart phone, enter the URL indicated in the ◆ preceding screen and then in the phone’s Web interface that opens, perform sign- in (as noted previously, this option is recommended if using MFA). - 42 -...
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual LLDP- MED (Link Layer Discovery Protocol – Media Endpoint Discovery) is a standard link layer protocol used by network devices to advertise their identity, capabilities, and neighbors on a local area network based on IEEE802 technology, principally wired Ethernet.
Page 51
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Sign in to the Teams admin center. Expand Devices. Select Provision new device from the Actions tab. In the ‘Provision new devices’ window, you can either add the MAC address manually or upload a file. Manually add a device MAC address From the Awaiting Activation tab, select Add MAC ID. Enter the MAC ID. Enter a location, which helps technicians identify where to install the devices. Select Apply when finished. Upload a file to add a device MAC address From the Awaiting Activation tab, select Upload MAC IDs. Download the file template.
Page 52
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual You'll need to provide the list of MAC IDs and verification codes to the field technicians. You can export the detail directly in a file and share the file with the technician who is doing the actual installation work. ➢ Step 3: Provisioning on the device Once the device is powered up and connected to the network, the technician provisions the device by choosing the ‘Settings’ gear on the top right of the new ‘Sign in’ page and selecting Provision phone. The technician is then expected to enter the device-specific Verification code that was provided in the Teams admin center on the phone’s user interface. Once the device is provisioned successfully, the tenant name will be available on the sign in page.
Page 53
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual ➢ Step 4: Sign in remotely The provisioned device appears in the Awaiting sign in tab. Initiate the remote sign-in process by selecting the individual device. Select a device from the Awaiting sign in tab. Follow the instructions in Sign in a user, and then select Close. The tenant admin is expected to complete authentication on the device from any browser or smartphone. - 46 -...
Page 54
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual When the tenant admin is signing in from Teams Admin Center, the user interface on the device is blocked to prevent other actions on the phone. - 47 -...
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Getting Acquainted with the Phone Screen The following gets you acquainted with the phone’s user interface. The figure below shows the phone's home screen, aka the phone's idle screen. The following figure shows the phone's Calls screen. The following table describes the phone's home screen. - 48 -...
Page 56
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Table 4-1: Calls Screen Item Description The phone menu. Select it to open the menu shown in the figure following this table. Calls Select the tab to open the Calls screen. The screen shown in the figure preceding this table opens. People Select the tab to open the People, shown under Using the People Screen on page 59 opens. Allows you to easily connect and collaborate with teammates, colleagues, friends and family. Through this screen, you can see all your contacts and create and manage contact groups to organize your contacts. The screen provides a simple user experience and aligns with the contacts on the Teams desktop client. If a contact has multiple numbers, the phone screen allows the user to select from a drop-down menu the intended contact method. Calendar Select to open the Calendar screen, shown under Setting up a Meeting on page 58 opens. Voicemail Select the tab to open the Voicemail screen, shown under Accessing Voicemail on page 60 opens. The following figure shows the user's presence status screen. Use this table as reference. Table 4-2: Menu Item Descriptions Item Description Presence status...
Connect a device See Connecting a Device for more information. Hot desk See Hot Desking on page 52 for more information. Settings See Configuring Teams Application Settings on page 55 for more information. Sign Out See Signing Out on page 61 for more information. Enabling Google Talkback AudioCodes’ Native Teams Android devices feature Google TalkBack, an accessibility service that allows blind and low-vision users to interact with their devices by giving them spoken feedback so they can use their devices without looking at the screen. The feature improves the experience of these users. ➢ To enable the feature: Open the Accessibility screen (Settings > Device settings > Accessibility). Select the TalkBack option shown in the preceding figure. Click OK to switch the feature on as shown in the preceding figures. Listen to the audio tutorial that begins playing. The tutorial explains how to interact with the device. ● After TalkBack is switched on, operations are performed by touching to select and then double-touching to activate.
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Select the phone icon; audio informs you that you can activate the person's profile. Double- touch the icon; the person's profile screen opens displaying their name, position, email, hyperlinked work phone number and hyperlinked mobile phone number. Select the star icon; audio informs you that you can add to Favorites; double-touch to activate it. Opting in or out of Call Queues Call queue agents can opt out of call queues or opt in based on settings a vailable on the Teams phones. Setting Status You can set a status message to add more substance to your presence status. For example, a status message such as 'Working from home' adds more substance to the presence status of 'Available'. ➢ To set presence status: In the home screen, select the user (avatar) picture. Select Set status message. - 51 -...
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Select the field under 'Set status message' and in the Virtual Keypad that pops up, type in the message you want to show other people, for example, 'Working from home'. The text you type in will replace 'Set status message' in the screen shown in the preceding figure. Optionally, switch on 'Show when people message me'. When people message or @mention you, they'll view the status message you set. Select 'Clear after' and choose when you want the message to stop displaying. Options are: ● Never clear ● 1 hour ● 4 hours ● Today ● This week ● Custom (set a date and time in the calendar that pops up) Hot Desking The hot desk feature allows a user to sign in to a phone that is already signed in to by another user without signing out the original user to whom the phone was assigned for primary use. Any phone in the enterprise network that is enabled with this feature allows any user in the enterprise to temporarily sign into it, make calls, attend meetings and access their calendar and call log. After finishing using these phone functions, the user can sign out to end their hot desk session; call logs and history will automatically be removed from the device. ➢ To set up a phone as a shared device for hot desking: Select the user's photo or avatar picture, and then from the menu, select the Hot desk option. Alternatively, in the Calls screen (or People screen, Calendar screen or Voicemail ...
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Figure 4-3: Hot desk Touch t he field 'Email, phone or username'. Figure 4-4: Email, phone or username Use the Virtual Keyboard to type in your email, phone or user name and then select Done; the phone is enabled for hot desk. Changing Presence Status You can assign a presence status to control whether you want people to contact you or not. By default, your status is based on your Microsoft Teams server. ● After n minutes (configured in the Teams server by your administrator), presence status automatically changes to ‘Inactive’.
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Select the current status displayed and from the drop-down list of statuses then displayed, select the status to change to. Use this table as reference. Table 4-3: Presence Statuses Presence Icon Description Status Available You're online and available for other contacts to call. Busy You’re busy and don’t want to be interrupted. Do not You don’t want to be disturbed. Stops the phone from ringing disturb when others call you. If DnD is activated, callers hear a tone indicating that your phone is busy; the call is blocked and your phone's screen indicates 'Missed Calls'. Be Right You'll be away briefly and you'll return shortly. Back Away You want to hide your status and appear to others you're currently away. Offline You're going on vacation (for example). Reset Resets the status. status Enabling Voicemail Support on CAP Users The instructions here show how to enable voicemail on common area phone users. Voicemail ...
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual ➢ To enable voicemail from the phone: In the phone screen, select the avatar. Navigate to Device Settings > Device administration. Enter the password 1 234. Access 'Teams Admin Settings' and select Calling. Enable Advanced calling. Restart the Teams app as prompted. ➢ To enable voicemail from the TAC: Under 'Teams Devices' in the Microsoft Teams admin center, select Phones. Go to Configuration Profiles; in the profiles there is an option under 'Calling settings' to enable Advanced calling. Configuring Teams Application Settings The following describes the Teams application's settings. In the home screen, select the user ...
Page 63
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Use this table as reference: Table 4-4: Idle Screen Description Item Description Dark Theme Dark Theme can be enabled to suit user preference. To enable Dark Theme: Drag the ‘Dark Theme’ setting slider to the ‘on’ position; the fol- lowing prompt is displayed: Choose Restart and then verify after the Teams application restarts that all screens (Teams application and Device Settings) are dark themed: - 56 -...
Page 64
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Item Description Profile Opens the user's email address and photo / avatar picture. Calling Opens the Calls screen. Incoming Calls ■ Call forwarding. Enables automatically redirecting an incoming call to another destination. ■ Forward to. Only displayed if the previous setting is enabled. Defines the destination to which to forward incoming calls.
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Item Description incoming calls. Select either Off, Voicemail, Contact or number, or Call group. Caller ID ■ Hide your phone number when dialing people who are outside of Microsoft Teams Block Calls Block calls with no caller ID. Enables blocking calls that do not have ...
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual You can join calendered meetings and / or you can select to add a new event to the calendar. Using the People Screen The People screen allows users to easily connect and collaborate with teammates, colleagues, friends and family. Through the screen, users can see all their contacts and create and manage contact groups to organize their contacts. The screen provides a simple user experience and aligns with the contacts on the Teams desktop client. In addition to accessing the People screen from the menu, the screen can also be accessed from the hard CONTACTS button on the phone. If a user creates a contact within Microsoft Outlook, their information appears under the People app on the phone screen. Contacts in Microsoft Outlook are available in read-only mode.
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Accessing Voicemail From the phone's home screen, select the Voicemail tab. Using Audio Devices Use one of the following audio devices on the phone for speaking and listening: ■ Handset: To make a call or answer a call, lift the handset off the cradle. ■ Speaker (hands-free mode) ● To activate it, press the speaker key during a call or when making a call. ● To deactivate it, press the speaker key again. Headset (hands-free mode). When talking on the phone, you can relay audio to a ■ connected headset. ● To enable it, press the headset key. ● To disable it, press it again. You can easily change audio device during a call. To change from speaker/headset to handset: Activate speaker/headset and pick up the ■...
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Transferring Calls and Meetings across Devices If a user joins a meeting on their PC, they’ll view a prompt suggesting adding their Teams device to split the audio and video, or transferring completely. The feature enables the user to move away from their PC while seamlessly staying connected. The phone recognizes the user is in a call on another device and prompts them to transfer or add, letting them start their call from elsewhere and transfer to their desk phone. Signing Out You can optionally sign out of the phone application and sign in as another user. ➢ To sign out: Under Settings, navigate to and select the Sign out option. Alternatively, in the Calls screen (or People screen, Calendar screen or Voicemail screen), select the phone menu , select the Settings option.
Page 69
CHAPTER 4 Teams Application C448HD C450HD | Users & Administrator's Manual Network administrators can alternatively sign out from devices using Microsoft Teams admin center (TAC). Network administrators can also remotely sign in and provision devices from Microsoft's TAC. - 62 -...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Performing Teams Call Operations The following documentation shows how to perform basic operations with the phone. Making a Call Calls can be made in multiple ways, for example, you can press the digit keys on the phone’s dial pad to enter the phone number or URL. Alternatively, select a call listed in the Calls screen, and then touch . Touching in the Calls screen allows you to make a call by entering the name of a contact. ● You need to touch the ‘To: Search for people' field to launch the soft keyboard. ●...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual ➢ To end a call before it's answered at the other end ■ Touch ➢ To dial a URL: Press the speaker key or lift the handset and then touch the ‘Place call’ field. Enter a URL address. To delete (from right to left), touch the clear key. If after activating the speaker and starting to dial a number you decide you don’t want to make the call, touch the key (shown in the figure below);...
Page 72
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual ➢ To dial the service from the locked idle screen either: Select the EMERGENCY softkey shown in the preceding figure of the locked idle screen and ■ then enter the emergency number. -OR- Dial from the locked idle screen without needing to use the EMERGENCY key: ■ Dial 911. Activate the speaker button on the phone. View the ‘Emergency call’ screen displaying the dialed emergency number. - 65 -...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual When the phone detects that 911 was requested, it automatically dials that number. Answering Calls The phone indicates an incoming call by ringing and displaying Caller X is calling you. The LED located in the upper right corner of the phone flashes red, alerting you to the incoming call. ➢ To answer: ■ Pick up the handset -OR - activate the headset key on the phone (make sure the headset is connected to the phone) -OR- activate the speaker key on the phone -OR- select the Accept softkey (the speaker is automatically activated). Ending an Established Call You can end an established call in a few ways. ➢ To end an established call: Return the handset to the phone cradle if it was used to take the call -or- activate the ■...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual ➢ To park a call: Put the call on hold and park it; you’ll receive a unique code from the Teams application. Communicate the code to another user who can then pick up the call on their device. The user on the other device selects the call park i con displayed in their device’s Calls screen. The user on the other device enters the code communicated to them and then selects the Pick up button to pick up the call. Managing Teams Meetings Multi- party conference meetings based on the Teams server (remote conference) can be calendered and initiated from the phone. ...
Page 75
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Touch NEXT. Touch Add participants. Touch the ‘To’ field and then use the soft keyboard to enter the first letter of the name of the participant to add. If you're searching for Alex (for example), touch the letter A on the soft keyboard, then l, etc.; the name you’re searching for will be promoted to the top of the list of Corporate Directory entries displayed. - 68 -...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual The feature lets you quickly and easily navigate to any employee listed in the Corporate Directory. Using Live Captions The phone can detect what's said in a meeting, group call or 1:1 call, and presents the text on the screen in real-time (live) captions. ● Captions are currently only available in English (US). ● Captions are currently unavailable for phones within government clouds. For more information, see here. - 69 -...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Raising a Hand During a Meeting During a meeting, you can raise a virtual hand from your phone to let people know you want to contribute without interrupting the conversation. Everyone in the meeting will see that you've got your hand up. For more information, see here. Hiding Names and Meeting Titles for Individual Devices Names and meeting titles can be hidden for individual devices. ➢ To hide names and meeting titles per device: Access the Meetings screen (More > Settings > Meetings) (the figure is for illustrative ...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Viewing and Playing Voicemail Messages If you hear a stutter dial tone when you pick up the handset, new messages are in your voicemail box. The phone also provides a visual indication of voicemail messages.
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Adjusting Ring Volume The volume of the phone's ring alerting you to an incoming call can be adjusted to suit personal preference. ➢ To adjust ring volume: When the phone is in idle state, select the VOL or VOL key on the phone. After adjusting, the volume bar disappears from the screen. Adjusting Tones Volume The phone's tones, including dial tone, ring-back tone and all other call progress tones, can be adjusted to suit personal preference. ➢ To adjust tones volume: Off-hook the phone (using handset, speaker or headset). Select the VOL or VOL key to adjust the volume. After adjusting, the volume bar disappears from the screen.
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual ➢ To adjust the headset volume: During a call, activate the headset key on the phone. Press the VOL or VOL key; the volume bar is displayed on the screen. Playing Incoming Call Ringing through USB Headset The phone features the capability to ring via a USB headset in addition to via the phone speaker. ...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual ➢ To view the details of a meeting: Scroll down if necessary to the meeting whose details you want to view and select it. Select See details and view in the right pane the details of the meeting. ➢ To join a meeting: ■ In the meeting you want to join, select the See details link and then select Join online meeting. Better Together over Bluetooth Applies only to C450HD. Read here about how to configure Better Together over Bluetooth with support for: ...
Page 82
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Install Teams PC Client on the PC. Sign in to the Teams PC Client with your account (it's necessary to sign in with the same accounts to both the Teams PC Client and to the device). ➢ To set up Bluetooth on the device side: Sign in to the Teams application with your account (it's necessary to sign in with the same accounts to both the Teams PC Client and to the device). Go to the hamburger menu on the device and click Manage devices. View the displayed available device to connect to. - 75 -...
Page 83
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Pair the device with your PC. View on your PC a notification it gets to accept the connection: Accept the notification from PC. Check the device and make sure pairing was successful: When pairing the phone with the PC Client, the PC Client presents the following request for approval: - 76 -...
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Once connected, the phone will be presented as a default Teams PC Client Audio device: Adding a Speed Dial ● Applies only to the C450HD phone with Expansion Module (sidecar). ● The feature expands the phone’s functional capabilities. ● Users can configure speed dials in the sidecar’s BLFs to speed dial frequently- used contacts with the press of a button, determine contacts’...
Page 85
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual Add it from the C450HD phone using one of the following options: ■ Via the Calls > Recent tab. Select a user and then select the ‘star’ icon to add them to the speed dial list: Via the People tab using + > Add from Directory and then add the users to the speed dial. - 78 -...
Page 86
CHAPTER 5 Performing Teams Call Operations C448HD C450HD | Users & Administrator's Manual The sidecar displays the user’s speed dial list. The list is synchronized on all devices under the same user account. The order on the sidecar corresponds to the order of the speed dial list.
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual Performing Administrator-Related Operations Network administrators can: Update phone firmware manually (see Updating Phone Firmware Manually on page 86 Manually perform recovery operations (see Manually Performing Recovery Operations on page 89 Remove devices from Intune management (see Removing Devices from Intune Management on page 90 Update Microsoft Teams devices remotely (see Updating Microsoft Teams Devices Remotely on page 98 Manage phones with the Device Manager (see Managing Phones with the Device Manager on page 98 Setting up an E911 Emergency Location using TAC An E911 emergency location can be set up using the Microsoft Teams admin center. ➢ To set up an E911 emergency location: In the TAC, go to Locations and in the 'Emergency addresses' page, set a new location by ...
Page 88
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual After the location has been set, click on the location and add a place (building, etc.). Make sure to maintain the hierarchy. C lick Apply and verify the place has been set. Enter the place you’ve set and define how to determine the emergency location. It can be determined by these values: ● Port ID ● Switch (Chassis) ID ● BSSID (Wi-Fi access points) ● Subnet ● User predefined location (see below for more details). - 81 -...
Page 89
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual The hierarchy of displaying a location is determined in the same order as above. Enter a location defined by a specific port ID. Make sure to enter the port description correctly, as delivered from your switch (* the switch must allow LLDP transmit and receive and provide LLDP information). Define a location defined by switch (Chassis) ID. T he location can be the same since a room defined in the previous step can reflect a room in a building using the same switch). - 82 -...
Page 90
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual Define a location by subnet. T he location can be defined like switch ID (if in charge of several buildings, since it reflects a perimeter or an area). Verify all settings have been implemented correctly, under the Networks & locations tab. - 83 -...
Page 91
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual Verify all settings have been implemented correctly, under the Networks & locations tab. - 84 -...
Page 92
After a location has been defined, make sure that: ● AudioCodes' phone runs the latest firmware released. ● AudioCodes' phone runs the Teams app issued June 2022 and later (U3-A and higher). ● E911 information is displayed on the phone screen 30-120 minutes after the location is set (time estimated under laboratory conditions).
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual Updating Phone Firmware Manually AudioCodes' Android Phone Utility allows network administrators to manually update a phone's firmware. ➢ To manually update a phone's firmware: From the PC's Start menu, select the app icon or click the application's exe file in the folder in which you saved it. - 86 -...
Page 94
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual In the 'Android Phone Address' field, enter the IP address of the device (get it by pressing the MENU hard key > About phone > Status > IP Address). Click SSH Connect; a connection with the device is established. Under the 'Single Operations' section of the screen next to the field 'Firmware file', click the Browse button and navigate to and select the candidate image file. Click the Submit button; a firmware upgrade process starts; the phone is automatically rebooted; a notification pops up when the process finishes. The phone notifies you that it's being updated and rebooted. - 87 -...
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual The above is also displayed when the phone is upgraded remotely from Microsoft Admin Portal or from AudioCodes' Device Manager. Downloading Certificates The following shows how to load user certificates to a single device and to multiple devices. Before loading certificates, put the certificate files in a designated folder. Certificates can be downloaded using: Device Manager (see the Device Manager Administrator's Manual) ■...
This feature resets the phone if Android is stacked and doesn’t respond (though Android stacking is unlikely); there’s no recovery process; the phone is only reset. All AudioCodes devices have a reset key or a combination of keys on the keypad to reset it. While a device is powering up, you can perform recovery operations by using a two- key combination.
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual Press key LED flashes 3x When? Action combination after release Start p ressing immediately Recovery m ode Back key + Red after power up (on U-Boot / (you can restore MENU key (3 Universal Boot Loader) defaults from there) seconds) Switch s lots A / B 4 ...
Page 98
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual The Endpoint Manager service is licensed according to individual terms. Con- sequently, not all network administrators will be able to navigate to it. Check if the license you're using includes the service or not. Click Devices.
Page 101
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual Select: OS > Android (Device Administrator) Device Action > Delete and then Next. Select Devices to include and search for the user for which enrolled devices are to be removed. - 94 -...
Page 102
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual Select all the devices to be removed and click Select icon. After the devices are selected, click Next. - 95 -...
Page 103
CHAPTER 6 Performing Administrator-Related Operations C448HD C450HD | Users & Administrator's Manual Click Create; a task to delete all the selected devices enrolled with a particular account is created. - 96 -...
C448HD C450HD | Users & Administrator's Manual Once the action is created, the admin receives notification. It may take some time to completely sync the devices with the account so after delet- ing the devices wait for 30 minutes before signing in. Configuring Audio-Related Parameters for Noisy Environments Network administrators can configure audio-related parameters to support the phone in special environments (such as noisy environments). To use the capability, contact AudioCodes Support. - 97 -...
➢ To apply the firmware from the USB disk: Enter recovery mode by simultaneously pressing the ‘back’ key + the MENU key; the device’s LED lights up red. Insert the USB disk with the target firmware. Figure 6-1: Apply update from a USB disk Select the ‘Apply update from USB disk’ option and then choose the correct firmware image from the disk. Managing Phones with the Device Manager AudioCodes' Device Manager manages Android-based Teams phones in a similar way to UC- type phones. Teams phones' configuration parameters are in the same format as UC phones. A .cfg configuration file is defined for each device. Device Manager version 7.8.2000 a nd later supports Android-based Teams devices. Zero Touch Provisioning is supported in a non-tenant aware manner; each local DHCP Option 160 must be configured with a fully-specified URL pointing to dhcpoption160.cfg as shown here: Table 6-1: DHCP Option 160 URL - 98 -...
After devices are added to the Device Manager, they're allocated to tenants by selecting Change Tenant in the ‘Actions’ menu. Unless already used, it's recommended to leave the default tenant as a ‘lobby’ for the new devices. The above URL can also be configured in AudioCodes' Redirect Server. Android-based Teams devices currently support: Provisioning of configuration ■...
Configuring TimeZone and Daylight Savings Network administrators can configure TimeZone and Daylight Savings to suit enterprise require- ments. AudioCodes' Teams phones feature a Automatic Time Zone Detection mechanism that allows the device to automatically detect the time zone via geographical location. If time zone is not configured, this feature is implemented.
➢ To establish an HTTPS connection: ■ The server certificate must be signed by a well-known Certificate Authority -OR- ■ A root/intermediate CA certificate must be loaded to the device’s trust store either via 802.1x or configuration parameter ‘ /security/ca_certificate/[0-4]/uri’ ➢ To maintain backward compatibility with devices previously running UC versions: ■ Configure parameter '/security/SSLCertificateErrorsMode' to Ignore Supported Parameters Listed here are the configuration file parameters currently supported by Android-based Teams devices. They're in AudioCodes’ UC version format. The parameters are comprised of Microsoft configuration profile settings and AudioCodes’ device-specific parameters. ■ general/silent_mode = 0 (default)/1 ■ general/power_saving = 0 (default)/1 phone_lock/enabled = 0 (default)/1 ■ ■ phone_lock/timeout = 900 (default) (in units of seconds) phone_lock/lock_pin = 123456 ■...
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual Troubleshooting The information presented here shows how to troubleshoot AudioCodes devices. DSCP The phone's Teams application supports DS (Differentiated Services) containing a differentiated Services Code Point (DSCP) value and an ECN (Explicit Congestion Notification) value, for monitoring Quality of Service (QoS). ...
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual Figure 7-3: Audio Users Read the following if an issue with your phone occurs. Contact your network administrator if necessary. Network administrators can also use this documentation as reference. Table 7-1: Troubleshooting Symptom Problem Corrective Procedure Phone is off Phone is not Make sure the AC/DC power adapter is attached ■ (no screen receiving firmly to the DC input on the rear of the phone. displays and power Make sure the AC/DC power adapter is plugged into ■ LEDs) the electrical outlet. ■ Make sure the electrical outlet is functional. If using Power over Ethernet (PoE), contact your ■ network administrator to check that the switch is powering the phone.
Android Phone Utility AudioCodes' IP phone is by default accessed via Secure Shell (SSH) cryptographic network protocol after the network administrator signs in. SSH is by default disabled and can be enabled with Administrator permissions in the phone screen (Device Administration >...
Page 113
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual In the 'Android Phone Address' field, enter the IP address of the device (get it by pressing the MENU hard key > About phone > Status > IP Address). Click SSH Connect; a connection with the device is established. Next to the field 'PC folder', click the Browse button and navigate to and select the folder to which to send data to use for debugging. - 106 -...
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual Capturing the Phone Screen AudioCodes' Android Phone Utility allows network administrators to effectively collaborate and debug issues using the screen-capturing feature. ➢ To capture the phone screen: Open the Android Phone Utility: From the PC's Start menu, select the app icon or click the application's exe file in the folder in which you saved it. In the 'Android Phone Address' field, enter the IP address of the device (get it by pressing the MENU hard key > About phone > Status > IP Address). Click SSH Connect; a connection with the device is established. Next to the field 'PC folder', click the Browse button and navigate to and select the folder to which to send the screen captures. Click the Screen Capture button; the phone's screen is captured and the screenshot is saved and sent to the folder. On your PC, navigate to the folder and retrieve the screenshot. Default file name: screencap.png. Rename it to a name related to the screen you captured. If you don't rename it, it will be overwritten the next time you take a screenshot. Running Tcpdump Tcpdump is a common packet analyzer that allows network administrators to display TCP/IP ...
➢ To run tcpdump without the utility: Access the phone via SSH and run the following commands: setprop ac.ac_tcpdump.timeout <seconds> After defining the capturing time as shown in the preceding command, start the capture: setprop ac.ac_tcpdump 1 Tcpdump capture file will appear in this location: /sdcard/recording/net.pcap After running Tcpdump, reproduce the issue. Execute the following command from your PC command prompt (cmd): scp -r admin@%deviceIp%:/sdcard/recording/ %FolderOnPc% Getting Information about Phones Network administrators can get information about phones using AudioCodes' SSH protocol based Android Phone Utility. ➢ To get information about the phone: Open the Android Phone Utility (see Android Phone Utility on page 105 for more information about the application), enter the phone's IP address, click the adjacent SSH Connect button and browse to a folder on the PC to which to send the information. Click the Get Version button. - 108 -...
Page 116
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual View the information in the pane. Alternatively: ● To get firmware information, in the 'Command' field enter the following and then click Send: getprop ro.build.id ● To get Bootloader information using SSH protocol, in the utility's 'Command' field enter the following and then click Send: getprop ro.bootloader ● To get DSP information using SSH protocol, in the utility's 'Command' field enter the following and then click Send: getprop ro.ac.dsp_version ● To get the Microsoft Teams version using SSH protocol, in the utility's 'Command' field enter the following and then click Send: getprop ro.teams.version ● To get the Microsoft Company Portal version using SSH protocol, in the utility's 'Command' field enter the following and then click Send: getprop ro.portal.version ●...
➢ To enable Remote Logging via Syslog from the Android Phone Utility: In the Android Phone Utility (see ndroid Phone Utility on page 105 for more information), enter the phone's IP address, click SSH Connect and browse to a folder on the PC to which to send the information. In the 'PC IP Address' field, enter the IP address of the PC on which the utility is installed and then click the Start Syslog button. Open the folder on the PC to which you commanded the application to send the information, and then locate the Syslog file. To view Syslog, you can optionally download the Syslog Viewer available in AudioCodes' website. ➢ To enable Remote Logging via Syslog from the phone: Log in to the phone as Administrator and go back. In the ‘Device administration’ screen, select Debugging. - 110 -...
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual Select Remote logging. Configure the ‘Remote IP address’ and ‘Remote port’ and enable ‘Remote Logging’; the device starts sending logs to the Syslog server. Network administrators can also enable Syslog using Secure Shell (SSH) protocol. ➢ To enable Syslog using SSH protocol, type the following command at the shell prompt: setprop persist.ac.rl_address <syslog_server_ip>:<port>. ➢...
Page 119
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual Select the Diagnostic Data option. Select OK to confirm. Wait until the screen shown in the preceding figure disappears; the phone creates all necessary logs and copies them to the its SD Card / Logs folder. Get the logs using SCP notation as follows: scp -r admin@host_IP:/sdcard/logs/ . Following are the relevant logs (version and ID may be different to those shown here): ■ - 112 -...
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual dmesg.log ✔ ✔ upstate-TEAMS_1.3.16-undated.txt ✔ dumpstate_log-undated-2569.txt logcat.log ✔ Activating DSP Recording Network administrators can activate DSP recording using AudioCodes' SSH protocol based Android Phone Utility. ➢ To activate DSP Recording: In the AudioCodes Android Phone Utility (see Android Phone Utility on page 105 for more information about the application), enter the phone's IP address, click SSH Connect and then click the Browse button next to the field 'PC folder' to configure a folder on the PC to which to send the information. In the 'PC IP Address' field, enter the IP address of the PC on which the utility is installed and then click the Start DSP Record button. After a period of recording, click Stop DSP Record. View the DSP recording in the PC folder you configured.
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual DSP recording can be activated on the fly without requiring the network administrator to reset the phone. Deactivating DSP Recording Network administrators can deactivate DSP recording using AudioCodes' SSH protocol based Android Phone Utility. ➢ To deactivate DSP Recording: In the utility (see Android Phone Utility on page 105 for more information about the application), click Stop DSP Record after a period of recording (see Activating DSP ...
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual SSH is by default disabled and can be enabled with Administrator permissions in the phone screen (Device Administration > Debugging > SSH). To sign in, the administrator needs to know their username and password; admin and 1234 are the defaults. SSH access allows administrators debugging capabilities such as: ■ Getting the Phone IP Address below ■ Pulling files from the phone sdcard (using the curl command) Activating DSP Recording on page 113 ■ ■ Deactivating DSP Recording on the previous page Installing the APK using SSH below ...
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual ➢ To upgrade the Android Package Kit (APK): Download the required APK to sdcard/teams.apk For example use the following: SCP <file name> admin@<DeviceIP>>:/sdcard/teams.apk Update the APK using the following: pm install -r -g /sdcard/<filename> Delete the old APK using the following: pm uninstall com.microsoft.skype.teams.ipphone If the new APK is older than the existing one, delete the existing APK before installing the new one.
➢ To collect logs: Reproduce the issue. Access Microsoft Admin Center and under the Devices tab click the Diagnostics icon. Figure 7-4: Microsoft Teams Admin Center - Diagnostics Applies to all AudioCodes phones for Microsoft Teams even though a specific model is shown in the figures here. Click the Diagnostics icon and in the 'Device diagnostics' prompt that pops up, click Proceed; log files are retrieved from the devices and uploaded to the server. - 117 -...
Page 125
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual Figure 7-5: Microsoft Teams Admin Center – Logs Upload to Server Click the History tab. Figure 7-6: History - Download Click Download to download the logs. - 118 -...
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual ● AudioCodes Device Manager's ‘Collect Logs’ action also includes all information collected by Microsoft Teams admin center (TAC). The .zip file includes the following files: ✔ Android BugReport ✔ AdminAgentLogs.zip - includes logcat collected by the OVOC/Device Manager.
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual Enable ‘Voice record’. Start Wireshark on your PC to capture the Audio traffic. Collecting Media Logs (*.blog) from the Phone Network administrators can collect Media Logs (*.blog) from the phone. ➢ To collect Media Logs (*.blog) from the phone Access the phone via SSH. SSH is by default disabled and can be enabled with Administrator permissions in the phone screen (Device Administration >...
Page 128
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual View all the interfaces on the phone and choose your preferred interface with which to capture packets. Port Mirroring Network Monitoring The phone supports the port mirroring network monitoring technique of copying and sending network packets transmitted as input from a phone port, to another port of a monitoring device for enhanced analysis and debugging capability. ➢ To enable the feature: ■...
Page 129
CHAPTER 7 Troubleshooting C448HD C450HD | Users & Administrator's Manual This page is intentionally left blank. - 122 -...
