Before Installation

Overall Layout Diagram

1
＜Front Layout＞
■ Top View
[ X ] [ Y ] (α) (β)
Chair
LUAR 117 1549 252 648
LEGEND 129 1533 264 636
INOVA 144 1513 279 621
DIVAN 114 1553 249 651
LUXURY MAXIM 117 1549 252 648
REGALOⅡ 105 1565 240 660
SET JOY ABLE 141 1517 276 624
macaron 143 1515 278 622 757
[X] and [Y] dimensions differ depending
on the type of chair using with YUME SWING.
Check the dimensions from the list as shown below.
(α, β, γ dimensions are for reference.)
■Side View (Seeing from A)
Basin Unit Height of neck fittings ( *1)
EX-YMSBXYM2
[YUME Basin]
(γ)
783
771
756
786
783
795
759
3000 or more
*When installing more than 1 unit, space between unit to unit to be 2200 mm or more.
774
Wall
A
Mirror center line
Edge of fixing base
Drain pipe center
Chair center
[Ｙ]
Chair maximum height
2
Caster rail F
Edge of fixing base
99
(Width of fixing base)
156 164.5
206
103.5 102.5 321 or more
135 36.5
8
34.5
Rotation
center
Fixing base
Hot water
supply
Rc1/2"
40 60 377
13m/m
H=60 (Cabinet)
317
Water supply
Rc1/2"
13m/m Plumbing cover
Drain
H=90
*Be sure to use the
VU/VP40
plumbing cover for
H=140
Under the floor plumbing.
Neck position
15
[Unit: mm]
Cabinet
73
