■ Y UM E N A GO M I
YUME NAGOMI/Ltype/GL1 （ WHITE）
AY-YMIXIL GL1
YUME NAGOMI/Ltype/GL2 （ BLACK）
GL2
YUME NAGOMI/Ltype/GL3 （ DARK BRAWN）
GL3
YUME NAGOMI/Ltype/GL4 （ MAROON）
GL4
AY-YMIXIHGL1
YUME NAGOMI/Htype/GL1 （ BLACK）
YUME NAGOMI/Htype/GL2 （ DARK BRAWN）
GL2
YUME NAGOMI/Htype/GL3 （ WHITE）
GL3
YUME NAGOMI/Htype/GL4 （ MAROON）
GL4
This product is designed for shampooing and hair/scalp care.
Operating Manual
(
Image is of
AY-YMIXIHGL*
Thank you for purchasing this Takara Belmont product.
The instructions contained in this booklet should be thoroughly read and understood
before use.
Using this product before reading this operating manual may result in an accident.
This product is an industrial shampoo unit designed for barber shops and hair salons.
Only use this product for its intended purpose and do not use it for non-hairdressing work.
Keep this manual and refer back to them when required.

Table of Contents

Description of Warning Symbols
Before Using This Product
)
Product Dimensions
1
2022.09
Version 3
2
2
6
8
9
9
10
11
11
11
12
14
21
27
27
27
28
29
29
29
30
31
32

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YUME NAGOMI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Takara Belmont YUME NAGOMI

Summary of Contents for Takara Belmont YUME NAGOMI

  • Page 1: Table Of Contents

    AY-YMIXIHGL* Product Dimensions Procedures for Daily Inspections Thank you for purchasing this Takara Belmont product. The instructions contained in this booklet should be thoroughly read and understood before use. Using this product before reading this operating manual may result in an accident.

  • Page 2: Safety Precautions

    These precautions are important for ensuring safety. Adhere to these precautions at all times. Takara Belmont is not responsible for any damage or risk to the person using this product or those around them due to accidents if this product is used without adhering to the "Safety Precautions", "Precautions for Use"...
  • Page 3 Warning Do not use with two or more people Disassembly and repairs/modifications are prohibited The seat must not be used by two or more people Disassembly at the same time. The maximum load of this Disassembly, repairs and modifications must not Prohibited product is 135 kg or less.
  • Page 4 Caution Do not use this product with the cover Do not use outdoors broken This product is designed for indoor use. Do not install this product outdoors or within a vehicle. Replace the cover if it breaks. Continuing to use Be sure to only use this product inside a barber or this product with a broken cover may cause a hair salon.
  • Page 5 Caution Do not place objects on this product Do not drink the hot water This product is designed for washing hair. Do not Only allow people to sit on the unit. Placing heavy drink the hot water. The water quality may cause objects on the unit may cause deformation and diarrhea or stomach pain.

  • Page 6: Precautions For Use

    Precautions for Use Caution Close the tap firmly Do not wipe with chemicals or apply heat After use or shampooing is complete, turn the tap firmly in a clockwise direction and turn the water Failure to follow this instruction may cause off...
  • Page 7 Takara Belmont shall not assume responsibility. After use, wipe water away from all parts other than the basin...

  • Page 8: Precautions For Handling Synthetic Leather

    Caution Do not use peppermint oil or aroma oil In cold regions, ensure that water is removed Do not use peppermint oil or aroma oil containing menthol. Failure to take this precaution may When using this product in winter in cold damage the resin parts, such as the shower regions, open the maintenance cover and open head, shower head holder, shower hose, tap,...

  • Page 9: Position Of Warning Labels

    Check that there are no scratches, cracks, or peeling of the plated surface of the knobs before Caution using the product. If peeling is observed, immediately stop using the product and contact your closest dealer or Takara Belmont. Continued operation may result in injuries. Example of Peeling of the Example of Scratches on the...

  • Page 10: Name Of Parts

    Name of Parts ■Main body Head cushion Neck cushion Back support cushion Backrest Shower head Seat/Legrest (seat portion) Shower head holder Armrest Basin Seat/Legrest (legrest portion) Armrest plate Reclining pedal Footrest Neck device Drain cap Thermostatic control knob Trap cover Shower hose Base cover...

  • Page 11: Accessories

    Accessories □ Sponge…１ □Drain cap…１ □Mohair tape for □Hair catcher…１ replacement...1 □Neck cushion…１ □Head cushion...1 set □Installation instructions…１ □Operating Manual…１ □Paper template…１ □YUME SPA Technical Manual(except for China)…１ □Operation Instruction Manual for Mohair tape …１ Precaution for Basin This product employs a ceramic basin. Since bending or deformation cannot be avoided when forming the basin, the position, height, or shape of the neck differs slightly from product to product.

  • Page 12: Preparations

    Preparations ■ Attach neck cushion Neck cushion (1) Align the neck cushion as shown in the illustration, and fit the neck cushion on the metal fittings. (Make sure the attachment Snap button Basin side orientation is correct.) Seat side The long edge faces The short edge faces the seat side the basin side...
  • Page 13 ■ Remove cover Turn the cover anticlockwise. Cover Turn the cover around 5 degrees. Pinch the front and back of the cover to deform and remove the catch. 【Image】 Catch Do not remove the cover of holder forcibly. Caution  Failure to follow the instruction may cause damage the product. ■...

  • Page 14: How To Use

    How to use ■ Operation Procedures Lead the customer in front of the chair, and as necessary slide out the footrest. ※When sliding out the footrest, As a guide, sliding out the footrest is necessary for lift it slightly so that the customers that are 158cm or shorter.
  • Page 15 After using the product, wipe off any moisture. 〇Moisture from the shower hose that dripped onto the floor. 〇Moisture adhered to the main unit cover and outside the basin. 〇Moisture collected in the water collection pan of the basin center cover. •...
  • Page 16 ■ Using the Dual function shower head Changing the selection switch position switches between Shower Mode and Low Splash Foaming Mode. Protrusion Selection switch <Shower Mode> <Low Splash Foaming Mode> Shower head • Press the switch on the side • Press the switch on the flat side. with the protrusion.
  • Page 17 ■ Adjusting the volume of water A left (counterclockwise) rotation of the tap increases the amount of hot water. A full left (counterclockwise) rotation of the knob will Open output the maximum amount. Close A full right (clockwise) rotation of the knob will stop the water.
  • Page 18 ■Adjusting the water temperature １ Turn the thermostatic control knob in the H or C direction to set the temperature to an appropriate level. Turning the knob toward H will make the water hotter, and turning (H) Hot it toward C will make it colder. Thermostatic control knob When adjusting the water temperature, reduce...
  • Page 19 ■To fill up basin with water To accumulate hot water for emulsification of hair color, <Accumulating the Water> rotate the drain cap in the clockwise direction to close the drain outlet. The amount of water should be below the level shown by the dotted line in the illustration on the below (just below the shower hose slot).
  • Page 20 ■ Securing the Neck Device (When rinsing after application of perming lotion) Carry out the following preparations before having the customer recline. ① Rotate the head cushions as in the illustration at right. ② Push out the neck fixing pin, and turn it clockwise ②...

  • Page 21: Maintenance

    Maintenance Never use volatile chemicals such as thinners, alcohol, gasoline or kerosene, cleaning products such as abrasive wax, a sponge with a scourer, detergents that include organic solvents, Caution acidic, alkaline or chlorine-based detergents, or scouring pads. Failure to follow this instruction may cause scratches or discoloration.
  • Page 22 • If scratching or damage appears on resin or plated parts such as the faucet handles, then immediately suspend use, and contact the closest dealer or Takara Belmont. Failure to suspend use may result in peeling plating or damage, leading hand injuries.
  • Page 23 ■ Sponge Sponge is consumable supply. Cover Replace the sponge if degradation causes rubbing sound when the hose is moving. (Available at additional cost) Remove the cover from the holder. [Page 13] • Remove the sponge from the hose and wash with water. Sponge •...
  • Page 24 ■ Basin body <Drain cap> Drain cap Wash around the drain cap, and remove any hair or dirt from chemicals. The drain cap is a consumable supply. Replace the drain cap if degradation causes water to leak quickly when the basin is filled with water. (available at an additional cost) Drain cap Gasket The drain cap must be detached from the drain...
  • Page 25 Cover the floor around the water and hot water supply pipe with cloth. Filtered • If there are electrical components such as wires check valve Water Drain hose nearby, ensure that water does not splash onto supply pipe  them. Failure to follow this instruction may Hot water Caution supply pipe...
  • Page 26 ■ Reclining pedal / Cover Wipe clean with a soft, dry cloth. If they are extremely dirty, wipe with detergent diluted with water, and always wipe them dry. Never use volatile chemicals such as thinners, alcohol, nail polish remover, gasoline or kerosene, cleaning products such as wax with a scourer, a sponge with a scourer, detergents that include Caution organic solvents, acidic, alkaline or chlorine-based detergents, or scouring pads.

  • Page 27: Daily Inspections

    Parts Replaced on a Regular Basis The following are parts that must be replaced on a regular basis as designated by Takara Belmont: □Drain hose: Replace every three years • For the drain hose, there is a possibility that water leaks will occur because cracks are caused due to deterioration and hardening of the hose from chemical agents in the drain water.

  • Page 28: Before Requesting Repairs

    Before Requesting Repairs If the following problems arise, conduct the checks outlined before requesting repairs. Symptoms Points to be checked Solutions • The backrest does not Is the wire snapped? 【If the wire is snapped】 ⇒ recline. For replacement of broken wires, contact your closest dealer.

  • Page 29: Consumable Supplies

    - Other parts (shower head, shower head holder, etc.). Disposing of This Product When disposing of this product or replaced parts, adhere to the effective regulations and dispose of them appropriately. After-sales Service To request after-sales service, contact your closest dealer or Takara Belmont directly.

  • Page 30: Specifications

    ・ Difference between hot-water supply pressure and water supply pressure: Within 0.2 MPa (2kgf/cm 102kg Weight Contents: Main unit 85kg Footrest 10kg Seat 10kg Maximam load 135kg or below ※For details of the hot-water supply temperature, hot-water/water supply pressures, see the YUME NAGOMI Installation Instructions.
  • Page 31 Product Demensions Outline drawing (Unit:mm 〔inch〕 ) H:When operated from standing position L:When operated from seated position ■ Top View End of chair Min. 80 Recommended min.spase of 2515 〔99〕 (min. 2365 〔93 1/8〕 for standing position) 〔3 1/8〕 Wall surface 1860 〔73 2/8〕...

  • Page 32: Procedures For Daily Inspections

    Procedures for Daily Inspections To ensure that this product can be used for a long period of time, conduct the inspections below. ■ Inspect the product every day Inspection item Inspection method If the inspection results show defects □Does the basin, □Slowly push the rear end of the □Rattling may cause incorrect operation or damage backrest or seat...
  • Page 33 Inspection item Inspection method If the inspection results show defects □Is there an abnormal □Check if there is an abnormal odor □Remove any hair and other objects trapped in the odor coming from the coming from the basin drain. hair catcher. (see page 21) basin drain? □Is there any water □Visually check around the main...
  • Page 34 MEMO...
  • Page 35 MEMO...
  • Page 36 TAKARA BELMONT CORPORATION 1-1, 2-Chome, Higashi-shinsaibashi,Chuo-ku,Osaka,Japan TEL : +81-6-6213-5945 FAX : +81-6-6212-3680 Printed in Japan 1E03U2B0...
