Takara Belmont YUME-iXi Operating Manual

Hide thumbs Also See for YUME-iXi:
Table of Contents

Advertisement

Quick Links

Download this manual
■ YU ME-i X i
AY-YMIXILGL1US YUME-iXi ／Ltype／GL1（WHITE）
  GL2
YUME-iXi ／Ltype／GL2（BLACK）
  GL3
YUME-iXi ／Ltype／GL3（DARK BROWN）
  GL4
YUME-iXi ／Ltype／GL4（MAROON）
AY-YMIXIHGL1US　YUME-iXi ／Htype／GL1（WHITE）
　　　 　GL2
YUME-iXi ／Htype／GL2（BLACK）
 GL3
YUME-iXi ／Htype／GL3（DARK BROWN）
 GL4
YUME-iXi ／Htype／GL4（MAROON）
This product is designed for shampooing and hair/scalp care.
YUME-iXi
Operating Manual
(
)
Image is of
AY-YMIXIHGL* US
Thank you for purchasing this Takara Belmont product.
The instructions contained in this booklet should be thoroughly read and understood
before use.
Using this product before reading this operating manual may result in an accident.
This product is an industrial shampoo unit designed for barber shops and hair salons.
Only use this product for its intended purpose and do not use it for non-hairdressing work.
Keep this manual and refer back to them when required.

Table of Contents

Name of Parts
Accessories
Preparations
How to Use
Maintenance
Daily Inspections
Specifications
MEMO
Version 6
1
2
2
6
8
9
9
10
11
11
11
12
14
21
26
26
27
27
28
28
29
30
31
33
May 2021

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YUME-iXi and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Takara Belmont YUME-iXi

Summary of Contents for Takara Belmont YUME-iXi

  • Page 1: Table Of Contents

    AY-YMIXIHGL* US Procedures for Daily Inspections MEMO Thank you for purchasing this Takara Belmont product. The instructions contained in this booklet should be thoroughly read and understood before use. Using this product before reading this operating manual may result in an accident.

  • Page 2: Description Of Warning Symbols

    These precautions are important for ensuring safety. Adhere to these precautions at all times. Takara Belmont is not responsible for any damage or risk to the person using this product or those around them due to accidents if this product is used without adhering to the "Safety Precautions", "Precautions for Use"...
  • Page 3 Warning Do not use with two or more people. Disassembly and repairs/modifications are prohibited. The seat must not be used by two or more people Disassembly at the same time. The maximum load of this Disassembly, repairs and modifications must not Prohibited product is 298 lb or less.
  • Page 4 Caution Do not use this product with the Do not use outdoors. cover broken. This product is designed for indoor use. Do not install this product outdoors or within a vehicle. Replace the cover if it breaks. Continuing to use Be sure to only use this product inside a barber or this product with a broken cover may cause a hair salon.
  • Page 5 Caution Do not place objects on this product. Do not drink the hot water. This product is designed for washing hair. Do not Only allow people to sit on the unit. Placing drink the hot water. The water quality may cause heavy objects on the unit may cause diarrhea or stomach pain.

  • Page 6: Precautions For Use

    Precautions for Use Caution Close the water stop handle firmly. Do not wipe with chemicals or apply heat. After use or shampooing is complete, close the water stop handle firmly. Failure to follow this instruction may cause Failure to turn the water off completely may deformation or discoloration.
  • Page 7 Takara Belmont shall not assume responsibility. After use, wipe water away from all parts other than the basin.

  • Page 8: Precautions For Handling Synthetic Leather

    Caution Do not strike the resin (plated) parts Do not use peppermint oil or aroma oil. with a hard object. Do not use peppermint oil or aroma oil containing menthol. Failure to take this precaution may Do not strike the resin (plated) parts, such as the damage the resin parts, such as the water stop knob, with a hard object.

  • Page 9: Position Of Warning Labels

    Check that there are no flaws, cracks, or peeling of the plated surface of the knobs Caution before using the product. If peeling is observed, immediately stop using the product and contact your closest dealer or Takara Belmont. Continued operation may result in injuries. Example of Peeling of the Example of Flaws on the...
  • Page 10 Name of Parts  Main body Head pillow Neck cushion Back support cushion Backrest Shower head Seat/Legrest (seat portion) Shower head bracket Armrest Basin Seat/Legrest (legrest portion) Armrest plate Reclining pedal Step Neck device Drain cap Water stop handle (with temperature control) Trap cover Shower hose Vacuum breaker...

  • Page 11: Precautions For Basin

    Accessories □Drain cap…1 □Hair catcher…1 □Mohair tape for □Sponge…1 replacement...1 □Neck cushion…1 □Head pillow...2 set □Installation instructions…1 □Operating Manual…1 □Paper template…1 □YUME SPA Technical Manual…1 □Operation Instruction Manual for Mohair tape …1 Precaution for Basin This product employs a ceramic basin. Since bending or deformation cannot be avoided when forming the basin, the position, height, or shape of the neck differs slightly from product to product.
  • Page 12 Preparations  Attach neck cushion Neck cushion (1) Align the neck cushion as shown in the illustration, and fit the neck cushion on the metal fittings. (Make sure the attachment Snap button Basin side orientation is correct.) Seat side The long edge faces The short edge faces the seat side the basin side...
  • Page 13 Preparations ■ Removing the cover Turn the cover counterclockwise. Turn the cover around 5 degrees. Cover Pinch the front and back of the cover to deform and remove the catch. 【Image】 Catch Do not remove the cover of bracket forcibly. Caution Failure to follow the instruction may cause damage the product.
  • Page 14 How to use ■ Operation Procedures 〇 A leather and basin may get damaged with a visitor's wrist watch, accessories, etc. In feeling danger, please request to remove it. Caution 〇 With tools, such as scissors, a ball and an exterior cover may get damaged. Please remove those tools, when you perform a shampoo operation.
  • Page 15 Check whether a visitor is comfortable. If needed, please have a position of a customer's hips shifted forward and backward, and tune it finely. <CHECK POINT> ①From an earlobe to the center of a neck [Guide] 0.4 - 0.8″from the customer's earlobe 　cushion is 0.4～0.8″.
  • Page 16 Manual Emergency Operation of the Backrest Reclining ＜Emergency operation when the reclining pedal does not work＞ Seat portion ① Remove the leg rest cushion. 1st layer 2nd layer 3rd layer (Held with Velcro) ② Remove the first layer of the seat cushion. Velcro (Held with Velcro) ③...
  • Page 17  Adjusting the volume of water Water stop handle the amount of hot water increases by pulling up the water stop handle. A full up of the handle will output the maximum amount. A full down of the handle will stop the water. <...
  • Page 18 ■Adjusting the water temperature Water stop handle Turn the water stop handle to set the temperature to an appropriate level. Turning the water stop handle toward left (counterclockwise) will make the water hotter,and turning it toward right (clockwise) will make it colder. (H) Hot When adjusting the water temperature, reduce the volume of water, point the shower head...
  • Page 19  To fill up basin with water To accumulate hot water for emulsification of hair <Accumulating the Water> color, rotate the drain cap in the clockwise direction to close the drain outlet. The amount of water should be below the level shown by the dotted line in the illustration on the below (just below the shower hose slot).
  • Page 20 ■ Securing the Neck Device (When rinsing after application of perming lotion) Carry out the following preparations before having the customer recline. ① Rotate the head pillow as in the illustration at right. ② Push out the neck fixing pin, and turn it clockwise ②...
  • Page 21 ● If scratching or damage appears on resin or plated parts such as the faucet handles, then immediately suspend use, and contact the closest dealer or Takara Belmont. Failure to 　 suspend use may result in peeling plating or damage, leading hand injuries.
  • Page 22 ■ Neck cushion, Head pillow At the end of work each day, wash the neck cushion and head pillow with water, wipe them dry with a towel, and allow them to dry in the shade.If they are extremely dirty, wash with detergent diluted with water, and rinse carefully with water.
  • Page 23 ■ Basin Wipe any dirt clean using detergent diluted with water. If streaked scratches appear due to contact with metallic objects such as watch bands, rub the area with a nylon scourer. Do not use a metallic scourer or Around the Caution sandpaper, as this will damage the basin.
  • Page 24  Basin body <Drain cap> Drain cap Wash around the drain cap, and remove any hair or dirt from chemicals. The drain cap is a consumable supply. Replace the drain cap if degradation causes water to leak quickly when the basin is filled with water. (available at an additional cost) Drain cap Gasket The drain cap must be detached from the drain...
  • Page 25 Sponge  Cover Sponge is consumable supply. Replace the sponge if degradation causes rubbing sound when the hose is moving. (Available at additional cost) Sponge Remove the cover from the bracket. [Page 6] - Remove the sponge from the hose and wash with water. Sponge holder - After washing the sponge with water, squeeze it like press- ing with both hands.

  • Page 26: Standard Duration Of Use

    Daily Inspections ● To ensure that this product can be used for a long period of time, follow the procedures outlined in "Procedures for Daily Inspections" on page 29 to 30 of this instruction manual. Always inspect this product following the procedures outlined in "Procedures for Daily Inspections". Continuing to use this product without performing the daily inspections may cause malfunctions or accidents.

  • Page 27: Before Requesting Repairs

    Before Requesting Repairs If the following problems arise, conduct the checks outlined before requesting repairs. Symptoms Points to be checked Solutions 【If the wire is snapped】 ● The backrest does not recline. → Is the wire snapped? For replacement of broken wires, contact your closest dealer.

  • Page 28: Disposing Of This Product

    Disposing of This Product When disposing of this product or replaced parts, adhere to the effective regulations and dispose of them appropriately. After-sales Service To request after-sales service, contact your closest dealer or Takara Belmont directly.
  • Page 29 ・Difference between hot-water supply pressure and water supply pressure: Within 29.0 psi (2.0 bar) 232lb Weight Contents： Main unit 188lb Step 22lb Seat 22lb Maximam load 298lb or below ※For details of the hot-water supply temperature, hot-water/water supply pressures, see the YUME-iXi Installation Instructions.

  • Page 30: Product Dimensions

    Product Demensions Outline drawing (Unit :inch) H:When operated from standing position L:When operated from seated position ■ Top View End of chair Recommended min.spase of 99 (min:93 1/8) for standing position) Wall surface Min:3 or furniture Wall surface or furniture Bolt Anchor Point ×6 Drain position 1/2"）...

  • Page 31: Procedures For Daily Inspections

    Procedures for Daily Inspections To ensure that this product can be used for a long period of time, conduct the inspections below. Inspect the product every day ■ Inspection item Inspection method If the inspection results show defects Does the basin, Slowly push the rear end of the Rattling may cause incorrect operation or damage □...
  • Page 32 Inspection item Inspection method If the inspection results show defects Water leaks may cause malfunctions to the main □ Is there any water Check that there is no water on □ □ body, or make dirt difficult to remove. Wipe water leaking from the main parts other than the inside of the away from all parts other than the inside of the...
  • Page 33 MEMO...
  • Page 34 MEMO...
  • Page 35 MEMO...
  • Page 36 TAKARA BELMONT CORPORATION U.S.A 101 Belmont Drive. Somerset,NJ 08873 800-526-3847 JAPAN 1-1, 2-Chome, Higashi-shinsaibashi,Chuo-ku,Osaka,Japan 1E043XA0 Book Number...
