SHAMPOO UNIT
This manual provides information and instructions for YUME SHAMPOO
UNIT. The instructions contained in this booklet should be thoroughly read
and understood before attempting to install the equipment.
After the installation is completed, file this manual and refer back to it
for future maintenance.
YUME
IMPORTANT
INSTALLATION
INSTRUCTIONS
Version 8
2023.12
1E00HQC0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the YUME and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Takara Belmont YUME

  • Page 1 INSTALLATION INSTRUCTIONS IMPORTANT This manual provides information and instructions for YUME SHAMPOO UNIT. The instructions contained in this booklet should be thoroughly read and understood before attempting to install the equipment. After the installation is completed, file this manual and refer back to it for future maintenance.
  • Page 2: Table Of Contents

    TABLE OF CONTENTS INSTALLATION INSTRUCTIONS 1. Overall View and Major Components ......1 2. Dimension & Specifications ........2 3. Plumbing Layout ............3 4. Contents of Unpacked Products ....... 4 5. Installation Instruction ..........5 5-1. Preparations for Installations ......5 5-2.
  • Page 3: Overall View And Major Components

    1. Overall View and Major Components ■Main Body Backrest Shampoo basin Seat Maintenance cover Main switch Foot control Neck cushion A sticker of drain hose replacement (Consumable) Head pillow (Consumable) Temperature control knob Body cover Shower head Mohair tape (inside cover) Shower hose Vacuum Breaker Safety lock cover...
  • Page 4: Dimension & Specifications

    2. Dimension & Specifications [ Unit:inch ] Line for Edge of Base Plate 20.5 Water Supply Hot Water Supply Drain Pipe Wall Wall Centre of Drain Pipe 23.6 (Base Plate) 28.7 50.0 Min.24.8(Sitting Position) Min.8.5 Min.16.9(Standing Position) 20.5 18.3 34.6 17.7 77.4 Min.117.3(Sitting Position) / Min.109.4(Standing Position) Type ----------------------- EX-YM*L, EX-YM*R, SU-YM...
  • Page 5: Plumbing Layout

    3. Plumbing Layout...
  • Page 6: Contents Of Unpacked Products

    4. Contents of Unpacked Product • YUME Main Body • Carriage Jig【OPTION】 • Jig A • Jig B Support Bar • Jig B Bracket Screws • Jig B • Seat and Backrest set ・Seat Cushion ・Seat Cover(R) ・Seat Cover(L) ・Screws ・Backrest Cover...
  • Page 7: Installation Instruction

    5. Installation Instruction 5-1. Preparations for Installations 1. Unpacking Remove nails from lower part of wooden crate. Lift up the upper portion of wooden crate. Chair will be left on the skid. Nails Nails 2. Remove the pump cover. 1. Remove the screws and remove maintenance cover, base cover left and right from main body.
  • Page 8: Marking For Unit Fixing Position

    5-3. Marking for unit fixing position Use supplied full scale template to mark the Marking fixing position on the floor. Check the piping and power outlet position before marking. Water Supply Pipe 1. Put the supplied template on the floor and hold with the tape etc.
  • Page 9 2. Hold the carriage jig and move the main unit to marked position on the floor. 3. Decide the installation position and remove the carriage jig A and B from main unit base. CAUTION Carriage Jig B Hold the Jig A and B to lift the unit by Carriage Jig A two workers to move it.
  • Page 10: Drain Pipe Connection

    5-6. Drain Pipe Connection Drain pipe(VU40) Elbow and drain pipe(VU40) are not included Drain Hose Gasket with shipment. Please prepare it beforehand. Stepped Section Insert the drain hose gasket 1. Insert the elbow to the drain pipe from floor with seals. to the drain pipe(VU40) until the stepped section hit to the end of drain pipe(VU40).
  • Page 11: Unit Power Supply Line

    5-8. Unit Power Supply Line Power Supply Cable 1. Fix the plug on the end of the unit power supply cable. Plug the unit power supply plug into the suitable power supply outlet. CAUTION This appliance is equipped with a cord having an equipment-grounding conductor and a grounding plug.
  • Page 12: Attach The Backrest And Seat Cushion

    5-10. Attach the backrest and seat cushion 1. Fix the seat cushion with six cap bolts(M5×15) 2. Fix the seat cover L & R with screws. 4. Backrest Cushion Attach the backrest cushion 3. Keep depressing backrest raising switch vertical to the backrest frame. until the backrest frame is raised position.
  • Page 13: Attach The Neck Cushion

    5-11. Attach the Neck Cushion Neck Cushion Snap Button 1. Attach the neck cushion on metal fittings as shown in figure. Fixed Pin Metal Fitting 2. Both side snap buttons of the neck cushion is fixed on a fixed pin. Snap Button Snap Button 5-12.
  • Page 14 NOTE...
  • Page 15 NOTE...
  • Page 16 TAKARA BELMONT CORPORATION U.S.A 101 Belmont Drive. Somerset,NJ 08873 TEL:800-526-3847 JAPAN 1-1, 2-Chome, Higashi-shinsaibashi,Chuo-ku,Osaka,Japan TEL:(+81)6-6213-5945 Printed in Japan...
