YUME HEADBATH
Operating Instructions
Instruction manual
Video (about 4 minutes)
https://beauty.takarabelmont.co.jp/
yume-headbath-videos/
Thank you for purchasing this Takara Belmont product.
Please read the Operating Instructions carefully before use and use the product correctly.
Failing to read the Operating Instructions before use may lead to accidents.
●Keep this booklet safe near the product so that it can be referred to promptly, and be sure to read this
booklet again when necessary.
●This product is an industrial appliance designed for use by hair and beauty salons. Only use this
product for its intended purpose.
●The product must only be used by professionals such as hair stylists and aestheticians.
If the Operating Instructions become illegible due to stains and tears, or if this booklet is misplaced,
please request a copy from Takara Belmont using the inquiry number shown in the box below.
Takara Belmont Shampoo Accessory
AY-YHBYM*/AY-YHBSS*
Model number:
(AY-YHBYM* shown in the figure)
1A0WPCA0 (inquiry number)
1
2022.06 (version 2)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Takara Belmont AY-YHBYM Series
Summary of Contents for Takara Belmont AY-YHBYM Series
- Page 1 ●The product must only be used by professionals such as hair stylists and aestheticians. If the Operating Instructions become illegible due to stains and tears, or if this booklet is misplaced, please request a copy from Takara Belmont using the inquiry number shown in the box below. 2022.06 (version 2)
-
Page 2: Table Of Contents
Table of Contents Introduction Description of Warning Symbols .................. Safety Precautions ...................... Precautions for Use ....................Accessories ....................... Names of Parts ......................Preparation Device Setup ......................Customer Setup ...................... Nozzle Arch Setup ....................Inner Bowl Setup ....................How to Use Performing Treatment ................... -
Page 3: Description Of Warning Symbols
Description of Warning Symbols ■Before using the product ... Please be sure to read the Safety Precautions and Precautions for Use carefully and use the product correctly. ■Precautions shown on this page These are intended for the safe use of the product and to prevent harm and damage to users and other people. -
Page 4: Safety Precautions
Safety Precautions (items that must be followed) WARNING When using or handling the product ... ●Avoid using hot water above 41°C in temperature ・This may cause burns. ・Check that the thermostatic control knob of the wash unit stops at the lock position. ・Check that the set temperature for the thermostatic control knob of the wash unit is 40°C or below. - Page 5 Diarrhea, abdominal pain, etc. may occur depending on the water quality. ●Avoid using the product with a damaged nozzle cover and base. In case of damage to the nozzle cover and base, contact your local Takara Belmont dealer immediately and have these replaced. Continued use without replacing these parts may result in failure or an accident.
-
Page 6: Precautions For Use
Precautions for Use ●Do not use for any purpose other than hair and beauty salon treatment This product is an industrial appliance for use in hair and beauty salons. Please avoid the use of the product outside these purposes. The product must only be used by those who have undergone appropriate training, such as hair stylists and aestheticians. -
Page 7: Accessories
Precautions for Use ●Be sure to use the neck cushion of the wash unit Neck cushion must be used as performing treatment without using the neck cushion may cause a burden on the neck and lead to injury. ●Clean the hair catcher of the wash unit frequently The hair catchers should be cleaned as frequently as possible. -
Page 8: Names Of Parts
Names of Parts Neck seal Backwash (YUME) basin specification Backwash (YUME) basin specification Sidewash basin/side neck specification Sidewash basin/side neck specification AY-YHBYMS/AY-YHBYMO AY-YHBSSS/AY-YHBSSO OASIS basin/backwash specification OASIS basin/backwash specification OASIS basin/sidewash specification OASIS basin/sidewash specification AY-YHBYMS2 AY-YHBSSS2 Nozzle arch Nozzle cover Nozzle Rubber band Rubber cover... -
Page 9: Device Setup
Device Setup ・This product is an accessory of wash unit for use for head bath. ・AY-YHBYMS/YMO are dedicated for use with the YUME series backwash (YUME) basin specification. ・AY-YHBSSS/SSO are dedicated for use with the YUME series sidewash basin specification. ・AY-YMS2/SSS2 are dedicated for use with the YUME series OASIS basin specification. -
Page 10: Customer Setup
Customer Setup １ Allow the customer to lie down Support the head of the customer and gently lower the head onto the neck cushion. Be sure to support the head of the customer with operator’s hand when lowering the CAUTION backrest of the chair to avoid injury caused by contact of the head with the basin. -
Page 11: Nozzle Arch Setup
Nozzle Arch Setup １ Remove the drain cap from the drainage outlet in the basin Check that the Nozzle cover nozzle arch is tilted The drain cap should be placed outside the towards the front. basin. ２ Attach the nozzle arch Nozzle arch Front side Insert the base rubber of the nozzle arch to... -
Page 12: Inner Bowl Setup
Inner Bowl Setup Attach the inner bowl Neck seal Lift the customer’s head and place the convex part Inner bowl of the inner bowl on top of the concave part of the rubber cover on both the right and left sides to attach the inner bowl. - Page 13 Performing Treatment ２ Pour hot water in the inner bowl (i) Check that the set temperature for the thermostatic control knob of the wash unit is 40°C or below. (ii) Fully open the tap on the wash unit. (iii) Check the hot water temperature with hands. (iv) To make the water output stable, wipe the nozzle with a finger while taking care to avoid wetting the customer’s face.
- Page 14 Performing Treatment ４ Perform head bath Adjust the angle of the nozzle arch while checking the state of water output. ・Care must be taken during use of this product to monitor the customer at all times. Sudden movement of the customer may lead to malfunctions and accidents. ・The customer’s head becomes warm during treatment.
-
Page 15: After Treatment
After the Treatment １ Hold the nozzle arch and tilt to the front, then stop the water. Nozzle cover ・Do not tilt the nozzle arch by Nozzle arch holding the nozzle cover Inner bowl because this may cause damage. CAUTION ・Stopping the water before tilting the nozzle arch to the front may cause residual hot... - Page 16 After the Treatment ６ Remove the nozzle arch Nozzle cover Remove the nozzle arch while avoiding contact with the customer, then store this in the dedicated Nozzle arch storage bag. [See figure below] * The bag is made of waterproof material; however, it is not designed to hold water.
-
Page 17: Maintenance Method
Maintenance Method Maintenance should be performed after using the product to keep it clean at all times. Stains left uncleaned may lead to the growth of mold. Some of the product’s metal parts and mechanical sections may be sharp. Care must CAUTION be taken when handling to avoid injury to the hands and fingers. - Page 18 Maintenance Method Filter １ Remove the urea screw, rubber band, rubber Rubber band holder, and the filter and clean the filter Urea screw Remove the filter by lifting the edge of the filter with the fingers. Rubber holder Filter Filter ２...
-
Page 19: Daily Inspection
Discontinue use and contact your local shower head is held securely. Takara Belmont dealer. Rubber bands and rubber holders are considered consumable goods. State of the neck Check for any tears or deformations The neck seal should be replaced. -
Page 20: Consumable Goods
In the case of significant wear and deterioration or damage, inspection or replacement of the parts will be necessary. Please contact your local Takara Belmont dealer immediately. Consumable goods (the following items are not covered under the guarantee and incur a charge) □Rubber band □Rubber holder □Inner bowl □Neck seal... -
Page 21: Disposal Of The Product
Disposal of the Product When disposing of the product or replaced parts, waste should be processed appropriately according to current laws and regulations in your country. Specifications Model number: AY-YHBYMS AY-YHBYMO AY-YHBYMS2 AY-YHBSSS AY-YHBSSO AY-YHBSSS2 Outer dimension:Refer Refer to the Product Dimension Diagram [page 22] Environment of use: Temperature: 10°C to 30°C Humidity: 90% or lower (without condensation) -
Page 22: Product Dimension Diagram
Product Dimension Diagram [U n i t : m m] Nozzle Arch AY-YHBYMS AY-YHBYMS 193(YMS/SSS/SMS2/SSS2) 182(YMO/SSO) Inner Bowl AY-YHBYM* AY-YHBYM*... - Page 23 Notes...
- Page 24 TAKARA BELMONT CORPORATION 1-1, 2-Chome, Higashi-shinsaibashi,Chuo-ku,Osaka,Japan TEL : +81-6-6213-5945 FAX : +81-6-6212-3680 Printed in Japan...
