Electric Esthetic Salon Bed
ESTHE BODY BED
SC - B11E
Model No.
Operating Instructions
Model No.
Thank you for purchasing this Takara Belmont
product.
Please read the Operating Instructions
carefully before use and use the product
appropriately. Thereafter, please keep the
Operating Instructions in a safe place and read
them again whenever necessary. Failing to read
the Operating Instructions before use may lead
to accidents.
Please note that this product is an industrial
appliance for use in esthetic salons and
hairdressing salons. Do not use the product for
any purpose other than esthetic or hairdressing
services. The product must only be used by
qualified professionals, such as estheticians
and hair stylists.
If you have any questions about the Operating
Instructions or the product, please contact us. If
the Operating Instructions become illegible due
to stains and/or tears, or if this booklet is
misplaced, please request a copy from Takara
Belmont.
SC-B11E
Table of Contents
.......................................
.......................................
..............................
.......................................
..............................
1A10QVA0
1-5
..................
6
.....................
7
............
8
9
10,11
12
..................
13
..................
14
15
...
15
............
15
...
16
...
17
......
18
July 2024 (Version 1)
(Inquiry No.)
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Takara Belmont ESTHE BODY BED
Summary of Contents for Takara Belmont ESTHE BODY BED
-
Page 1: Table Of Contents
… SC-B11E Model No. Disposal of The Product ………… Environmental Conditions Regarding Transportation Thank you for purchasing this Takara Belmont and Storage (Management) … product. Please read the Operating Instructions Maintenance and Inspection … carefully before use and use the product appropriately. -
Page 2: Safety Precautions
Safety Precautions Signs and symbols of safety hazards ■Before using the product Please be sure to read the Safety Precautions carefully and use the product correctly. ■Precautions shown on this page These precautions are intended for the safe use of the product and to prevent hazards or damage to you or other people. - Page 3 ● Warning when connecting with power and ground WARNING ● Plug this product alone into the outlet. Use a separate outlet. Sharing the outlet with other equipment may generate abnormal heat or an outbreak of fire. ● Insert the power plug fully. Insert the power plug fully into the outlet.
- Page 4 If foreign matter enters the equipment’s housing, turn off the main switch immediately, disconnect the power plug, and contact your local authorised Takara Belmont dealer. ● Do not place liquid containers on top of or near this product.
- Page 5 Otherwise, personal injury or property damage may result. Please contact our call center. Please contact your local authorised Takara Belmont dealer. ● The device must not be disassembled or repaired by people other than qualified...
- Page 6 Carefully and routinely inspect for any looseness, backlash, inclination, vibration, noise, temperature, odor, etc. If you notice anything strange, stop use immediately, turn off the main switch, disconnect the power plug, and contact your local authorised Takara Belmont dealer. ●...
-
Page 7: Precautions For Use
Precautions for Use (Safety and Hazard Prevention) 1. The product must only be used by skilled professionals. 2. Pay attention to the following items when installing equipment. (1) Install the equipment in an area where it will not be exposed to water. (2) Install the equipment in an area free from potential negative influences from atmospheric pressure, temperature, humidity, ventilation, sunlight, dust, or air with high salt or sulfur content. -
Page 8: Warning Label Locations
Warning Label Locations ここに手を入れないください。 はさまると、大きなケガをするお それがあります。 PINCHING DO NOT insert finger or hand into this space. Serious injury may occur by pinching. -
Page 9: Part Names
Operating Instructions (1) Main unit DN side Main unit UP side Main unit raising/lowering foot pedal In the event of damage to the appearance of this product or the absence of included parts, please contact your local authorised Takara Belmont dealer. -
Page 10: Installation
Installation 1. Checking the installation location Before and during operation, check carefully for any objects or body parts, such as hands or feet, that might be within or near the product’s operating WARNING range. Otherwise, the object or body part might become caught in the product, and personal injury or property damage may result. -
Page 11: Preparation
Preparation 1. Connecting the foot control Firmly insert the foot switch plug into the control box located under the center of the table. Table Pass the foot control cord between the bases so that the cord does not get caught between the devices. - Page 12 3. Turning on the power Picture shows an image. (1) Insert the power plug. ● If the outlet has a ground terminal, simply insert the power plug. ● If the outlet does not have a ground terminal, ensure a proper ground connection to prevent electric shock in the event of current leakage.
-
Page 13: Method Of Operation
Method of Operation This product must be operated by a salon technician using the foot control. Do not use for purposes other than esthetic treatments. Foot control Table DN side Table UP side Table raising/lowering foot pedal Raising and lowering the table Raise: The table rises while the user depresses the Table Lower: The table lowers while the user depresses the UP side of the table raising/lowering foot pedal... -
Page 14: Moving This Product
Moving This Product 1. Lower the table to the lowest limit. 2. Turn off the main switch and disconnect the power plug. 3. Hold the base part as shown in the figure below and move the product. 4. After moving, make sure to stably place this product by using level adjusters. (See “Installation 2. -
Page 15: After Use
After Use 1. Please turn off the power after use or when this product is not in use. Turning off the power FUSE (1) After use or when this product is not in FUSE use, press the lower side (〇 side) of the ○... -
Page 16: Storage (Use) Environment
Do not store the equipment near any area where chemical agents are stored or gases are generated. 2. Service life ● The service life of this product is 10 years. [Based on self-certification (Takara Belmont data)] ● The service life of cushion parts, such as the table, and switches, may vary depending on the use environment. -
Page 17: Maintenance And Inspection
Maintenance and Inspection Maintenance and inspection guide (maintenance and inspection by users) For long and safe use of this product, it must be inspected as listed below at the specified frequencies. Inspection Maintenance work required if the Inspection method/diagnosis Impact of not inspecting Inspection item frequency inspection result is “failure”... -
Page 18: Before Requesting Repair
Has the adjuster been adjusted? See “Installation 2. Use of a level backlash/tilt. adjuster” (on page 9). If the above troubleshooting does not return the product to normal operation, stop using it, disconnect the power plug, and contact your local authorised Takara Belmont dealer. -
Page 19: Specifications
Specifications 1900 1500 (Unit: mm) (1) Main unit dimensions ........………………………………………1900mm×700mm Accessory headrest .........………………………………………… 150mm×300mm (2) Main unit raising/lowering range ........………………………530mm-830mm (Motor type) (3) Product weight ........………………………………………………………………60kg (4) Electrical rating ......……………………………………… AC220/230V 50/60Hz 0.8A (5) Control operating voltage ........………………………………………………DC24V (6) Continuous duty ……………........…………………………………Duty cycles 10% (7) Maximum load ………………........………………………………………………135Kg... - Page 20 TAKARA BELMONT CORPORATION 1-1, 2-Chome, Higashi-shinsaibashi,Chuo-ku,Osaka,Japan TEL : +81-6-6213-5945 FAX : +81-6-6212-3680 Printed in Japan...
